Product Description
Product Description
Magnetic tumbling polishing machine is a new type of grinding equipment that uses the force of a magnetic field to guide the rapid rotation of the grinding material (magnetic needle), thereby performing grinding, polishing, cleaning and other operations on the surface of the workpiece. This type of machine has advantages such as efficiency, precision, and environmental protection, and can be used for grinding and polishing materials such as metals and non-metals.
The usage method of magnetic tumbling polishing machine is as follows:
Preparation of materials: First, prepare the workpiece that needs to be ground and polished, as well as the corresponding grinding materials, such as abrasives, grinding tools, grinding fluids, etc.
Installation of abrasive: Distribute the abrasive material evenly on the turntable inside the grinder and fix it properly.
Adjusting the speed: Adjust the speed of the equipment as needed. The higher the speed, the higher the grinding efficiency, but it will cause significant wear on the surface of the workpiece.
Insert workpiece: Place the workpiece that needs to be ground and polished into the grinder, ensuring that the workpiece is in contact with the abrasive.
Starting equipment: Turn on the power of the grinding machine, start the equipment, and adjust the position and angle of the nozzle to evenly spray the grinding fluid on the workpiece and abrasive.
Grinding operation: Observe the operating status of the equipment, adjust the speed and nozzle in a timely manner to ensure the grinding effect. When the grinding marks on the surface of the workpiece become shallow, finer abrasives can be replaced or the particle size of the grinding tool can be adjusted.
Cleaning and completion: After the surface of the workpiece reaches the required polishing effect, turn off the equipment, remove the workpiece, and perform cleaning and inspection.
It should be noted that when using a magnetic tumbling polishing machine, safety precautions should be taken to avoid abnormal situations during machine operation, and timely shutdown should be carried out for inspection and problem-solving. At the same time, pay attention to the maintenance and upkeep of the equipment to ensure its normal operation and effectiveness.
The working principle of a magnetic tumbling polishing machine is to adsorb abrasive onto a rotary table through magnetic force, and use the high-speed rotation of the rotary table to drive the abrasive to move, thereby grinding, polishing, cleaning, and other operations on the surface of the workpiece. The movement of abrasive is achieved through the rotation of the rotary table and the guidance of magnetic force. While the abrasive rotates at high speed, it also undergoes complex movements, including rotation, translation, vibration, etc., in order to fully cover the surface of the workpiece and achieve the effect of grinding and polishing.
>>
