Long Lasting 63V 100000UF 2000hrs Power Aluminum Electrolytic Capacitor

Product Description

ITEM	4 × 5.4	5 × 5.4	6.3 × 5.4	6.3 × 7.7	6.3 × 10.5	8 × 6.2	8 × 10.5	8 × 12.5	10 × 10.5	10 × 12.5	12 .5× 13.5	12.5 × 16.5	16 × 16.5	18 × 16.5	18 × 21.5
A	1.8	2.1	2.4	2.4	2.4	2.9	2.9	2.9	3.2	3.2	4.8	4.8	5.8	6.8	6.8
B	4.3	5.3	6.6	6.6	6.6	8.3	8.3	8.3	10.3	10.3	13	13	17	19	19
C	4.3	5.3	6.6	6.6	6.6	8.3	8.3	8.3	10.3	10.3	13	13	17	19	19
E	1.0	1.3	2.2	2.2	2.2	2.3	3.1	3.1	4.5	4.5	4.4	4.4	6.4	6.4	6.4
L	5.4	5.4	5.4	7.7	10.5	6.5	10.5	12.5	10.5	12.5	13.5	16.5	16.5	16.5	21.5
H	0.5~0.8						0.8 ~ 1.1				1.1~1.4

Package quantity

ФD×L	Quantity / Reel	pcs/ Small packing box	pcs/Large packing box
4×5.4	2000pcs	24000pcs	48000pcs
5×5.4	1000pcs	12000pcs	24000pcs
6.3×5.4,6.3×7.7,8×6.2	1000pcs	10000pcs	20000pcs
8×10.5,10×7.7,10×10.5	500pcs	3500pcs	7000pcs
6.3×10.5	800pcs	8000pcs	16000pcs
8×12.5	400pcs	2800pcs	5600pcs
10×12.5	400pcs	2800pcs	5600pcs
12.5×13.5	200pcs	1200pcs	2400pcs
12.5×16.5	150pcs	900pcs	1800pcs
16×16.5	125pcs	625pcs	1250pcs
18×16.5	125pcs	625pcs	1250pcs
18×21.5	75pcs	375pcs	750pcs

63V 100000uF Aluminum Electrolytic Capacitor,Screw Terminal Capacitor 63V 100000MFD
Product Name:Screw Terminal Aluminum Electrolytic Capacitor
Series:CD135
Operating Temperature Range°C:-40~+85°C
Working Voltage Range:10~450V DC
Capacitance Range:270~820000uF
Load life:2000Hours

CD135 Screw Terminal Aluminum Electrolytic Capacitor

Capacitance	270~820000µF
Voltage Rating	10~450V DC
Tolerance	±20%
Lifetime @ Temp.	2000 Hours @ 85°C
Operating Temperature	-40°C ~ 85°C
Ripple Current
Size / Dimension
Case	Screw Terminal
Features	Load life of 2000 hours at 85°C
Applications	Inverter & Power Supplies
Packaging	6~12pcs Per Carton

Features:
(1)all-welded construction ensures reliable electrical contact;
(2)high reliability and high ripple current capability;
(3)RoHS compliant.

Construction:
(1)Charge-discharge proof, polar;
(2)aluminum case with insulating sleeve;
(3)poles with screw terminal connection;
(4)mounting with ring clips , clamps or thread stud.

63V Specification:

Specification		Size (mm)	Part Number
63V (79V) 1J	3900uF	36X53	ECG1JBP392MA053**
	4700uF	36X53	ECG1JBP472MA053**
	5600uF	36X53	ECG1JBP562MA053**
	6800uF	36X65	ECG1JBP682MA065**
	8200uF	36X83	ECG1JBP822MA083**
	10000uF	36X83	ECG1JBP103MA083**
	12000uF	36x100	ECG1JBP123MA100**
	15000uF	36x100	ECG1JBP153MA100**
	18000uF	36x121	ECG1JBP183MA121**
	22000uF	36x121	ECG1JBP223MA121**
	27000uF	51X96	ECG1JBP273MC096**
	33000uF	51X96	ECG1JBP333MC096**
	39000uF	51x115	ECG1JBP393MC115**
	47000uF	51x130	ECG1JBP473MC130**
	56000uF	64x115	ECG1JBP563MD115**
	68000uF	64x121	ECG1JBP683MD121**
	82000uF	64x130	ECG1JBP823MD130**
	100000uF	77x115	ECG1JBP104ME115**
	120000uF	77x130	ECG1JBP124ME130**
	150000uF	77X155	ECG1JBP154ME155**
	180000uF	90x131	ECG1JBP184MF131**
	220000uF	90X157	ECG1JBP224MF157**

Dimensions
