FTTH Drop Cable Kfrp Fiber Optic Cable Gjxfh-1, 2, 4 B6. A2

US$10.00-200.00 20 km (MOQ)

Basic Info.

Model NO.

GJXFH-1, 2, 4-KFRP

Material Shape

Round Wire

Allowed Lateral Pressure

500n/100mm

Core

Single Core

Certification

RoHS, CE, ISO9001

Brand

Daytai

Sheath Material

LSZH

Cable Type

GJXFH-1,2,4b6.A2

Cable Dimension

3.0mm X 2.0mm

Cable Weight

7.5kg/Km

Fiber Type

9/125 (G.657A2)

Fiber Color

Nature,Blue,Orange,Green

Sheathmaterial

LSZH

Sheath Color

White or Black

Short Term Tensile

80n

Crush Resistance

500n/100mm

Operation Temperature

-20~+70

Transport Package

1km or 2km Per Reel

Specification

EU, RoHS

Trademark

Daytai

Origin

Zhejiang, China (Mainland)

Production Capacity

250000 Kilometer/Kilometers Per Month

Product Description

FTTH Drop cable,GJXFH 1,2,4 Core,G.657A fiber,fiber color:Nature,Blue,Orange,Green or specify,
Attenuation:<= 0.4 at 1310nm, <= 0.3 at 1550nm (dB/KM),Min. bending radius:10mm
(Static) 25mm (Dynamic),Short term tensile:80N,Crush resistance:500N/100mm,Sheath
material:LSZH,Sheath Color:White or Black,Cable Dimension:3.0mm x 2.0mm,Cable
Weight :7.5Kg/Km,PACKING:1KM or 2KM / Drum is optional.

Item	Technology parameter
Cable type	GJXFH-1,2,4B6.A2
Cable Dimension	3.0mm x 2.0mm
Fiber type	9/125 (G.657A2)
Fiber Counts	1	2	4
Tight buffer color	Nature	Nature,Blue	Nature,Blue,Orange,Green
Sheath material	LSZH
Sheath Color	White or Black
Cable weight	7.5Kg/Km
Min. bending radius	10mm (Static) 25mm (Dynamic)
Attenuation dB/km	<= 0.336 at 1310nm, <= 0.198 at 1550nm
Short term tensile	80N
Crush resistance	500N/100mm
Operation temperature ºC	-20~+70
