| Processing scope and capacity | Maximum turning diameter | 550mm |
| maximum machining diameter | 330/350mm |
| Maximum processing length (one clamp one top) | 520mm |
| travel stroke | X-axis travel | 190mm |
| Z-axis travel | 580mm |
| Tail seat shaft travel | 440mm |
| main spindle | New generation motor output power (30min/continuous) | 11/15KW |
| Main shaft end form | JISA2-6 |
| Main shaft speed ★ 1 | 10-4500rpm |
| chuck | 8 inches (optional 10 inches) |
| through hole diameter | 62mm |
| turret | Tool capacity | 8 / 12 |
| Tool division time | 0.2 seconds/position |
| Tool body size | 25mm×25mm /20mm× 20mm |
| Maximum boring tool diameter | 40mm/ 32mm |
| New generation motor power | 1.1KW |
| Tailstock | Transmission form | Servo programmable |
| Conical hole form | MT.NO.4 |
| New generation motor power | 1.7 KW |
| Feed | X-axis fast forward speed | 30000mm/min |
| New generation motor power | 2.4KW |
| Z-axis fast forward speed | 36000mm/min |
| New generation motor power | 2.4KW |
| Coolant passage | volume | 150L |
| Else | Power source (continuous) | 18KVA |
| floor space | 2318(L) × 1585(W)× 1770(H) |
| Net weight of machine tool | 4500Kg |
| power requirement | 3380V +10%~ -15% |
| ambient temperature | 0~40ºC |
| Relative humidity of the environment | ≤85% |
