| No. | Item | Specification | Remarks | |
| 1 | Brand Name | OEM | ||
| 2 | Model No. | IFR12V6Ah-12Ah | ||
| 3 | Normilar Capacity | 6Ah 10Ah 12Ah 4S3P by 26650 x 12pcs | 0.2 C5A discharge | |
| 4 | Nominal Voltage | 12.8V | ||
| 5 | Discharge Voltage (Min.) | 7.5V | ||
| 6 | Charging Voltage (Max.) | 14.6V | ||
| 7 | Charging Current (std.) | 0.2 C5A | ||
| 8 | Discharging Current (Max. continue) | 2 C5A | ||
| 9 | Discharging Current (Max. temporary) | 3 C5A | ||
| 10 | Charging Temperature & Humidity | 0℃ ~ +45℃ 45~85%RH | ||
| 11 | Discharging Temperature & Humidity | -20℃ ~ +60℃ 45~85%RH | ||
| 12 | Battery storage and transportation environment temperature & humidity ranges | Min. 1 month | -20℃ ~ +60℃ 45~85%RH | |
| Min. 3 months | -20℃ ~ +45℃ 45~85%RH | |||
| Min. 12 months | -20℃ ~ +25℃ 45~85%RH | |||
| 13 | Battery Type | LiFePO4 battery 26650 3000mAh-4000mAh | ||
| 14 | Internal Impedance | |||
| 15 | Protection Fuctions | Over charge, Over discharge, Over load, Short Circuit | ||
| 16 | Size | 150*65*95 mm | ||
| 17 | Weight | Approx. 1.05kg with plastic case | ||
| 18 | Cycle Life | 5000 times | ||
| 19 | Warranty | 12 months | ||
