| Chassis parameters |
| Chassis model | QL1160AMFRY | Chassis brand | ISUZU |
| Overall dimensions | 7570×2490×2750mm | Wheel base | 4500mm |
| Front/rear wheel track | 1960/1855mm | Front/rear suspension | 1335/1735mm |
| Approach/departure angle | 15/17° | Maximum speed | 105km/h |
| Chassis Manufacturer | QingLing Motors (Group) Co., Ltd. |
| Cab | Configuration | FVR,double rows cab,allowable 3+3 passengers,with air conditioner, central locking, electric windows, USB audio, cab can be flipped. |
| Color | Red,other color is optional |
| Engine | Model | 6HK1-TCNG40 |
| Emission | Euro 4 |
| Type | 6 cylinders, in-line, 4-stroke,Exhaust gas turbo ,diesel engine |
| Rated power | 240hp |
| Displacement | 7780ml |
| Manufacturer | Isuzu Engine (Chongqing) Co., Ltd. |
| Tire | Size | 10.00R20 |
| Number | 6+1 nos |
| Front axle | 6.3 tons |
| Rear axle | 13.0 tons |
| Drive form | 4X2 |
| Suspension | Multi leaf springs |
| Rated voltage | 24V,DC |
| Transmissions | Isuzu MLD six speed transmission,6 speed forward 1 reverse. |
| Steering device | Power assisted steering |
| Steering wheel | Left hand drive |
| Selective configuration | 11.00-20,11.00R20 |
| If there is a slight change in the chassis parameters above,please take the actual product as the standard |
