Automatic Pet Water Bottle Blow Moulding Machine (BM-A4)

Product Description

Automatic PET Water Bottle Blow Moulding Machine
Technical parameters:
Model: BM-A4000 Bottle Blow Moulding Machine
Productivity: Depend on bottle design, 3200-4000PCS/H
Product type: Body diameter, 20mm-100mm
Height: 50mm-350mm
Neck diameter:15mm-38mm
Mold Cavity: 4cavities
Mold thick: 240mm
Mold: 500*500mm
Main machine power: Electrical source power 380v 3Phase /220v 3Phase 50/60HZ
Rated Power: 49kw
Really use power:14kw
Air sourceLP air compressor:1.6m3/min 1.0MPa 1set (15KW)
HP air compressor: 1.0m3/min 3.0MPa 2sets (each set 11KW)
Air dryer: 2.0m3/min 3.0MPa 1set
Cooling water Cooling water:15L/min
Size: L*W*H1908*1858*1920mm
Weight: 3600kg
Preform unscrambler: L*W*H2000*950*2480mm
Weight: 250kg
Resin available PET

---
