Security monitoring radar scanning detection system radar scanning detection linkage video control radar

Product Details

Product Description

Product Description
Ground directed search radar
Radar system
Linear frequency modulated continuous wave radar system
Detection range
200m~10km (natural person)
200~15km (vehicle)
Measurement accuracy
Azimuth measurement accuracy (rms) ≤1°
Distance measurement accuracy (rms) ≤4m
Detection range
Azimuth: 20°
Pitch beam Angle: 20°
Detectable target speed: (0.5~60) m/s
Radar weight/radar body: 10kg
Continuous working time: 7×24 hours
Mains working status
Multi-objective processing capability
TWS tracking: 10 batches
Loading mode: stationary and vehicle-mounted
Reliability maintainability
MTBCF: ≥20000 hours;
MTTR: ≤0.5 hours
Interface: Ethernet
Environmental adaptability
Operating temperature: -25℃ ~ +55℃;
Storage temperature: -25℃ ~ +65℃.
Humidity: ≥ (95±3)% at +35℃;
Rain resistance: medium to heavy rain;
Anti-dust, anti-salt spray;

---
