Skj Serious Flat Die Wood Pellet High Efficiency Motor Machine

Product Description

DEXI Flat Die Wood Pellet Machine
Product Description
The SKJ Small pellet mill is good for press different kind of wood sawdust, grass, straw, ground nuts shell, corn straw and other agriculture waste into animal feed pellets or biomass pellets.

SKJ flat die small pellet mill using the high efficiency motor to provide the power transfer through the industry strong gearbox. The gearbox type flat die pellet mill is stronger than normal rear axle differential type. This is better for biomass pellet making, or press different kind of straw for cow feed, horse feed pellet making.
Product Parameters

Model	Power (kw)	Capacity for Wood pellets(kgs/h)	Weight of the machine(kgs)	Dimension of the machine (mm)
SKJ2-250B	15	100-200	400	1120x440x1060
SKJ2-300B	22	200-400	800	1280x560x1220
SKJ2-350B	30	300-500	900	1300x530x1220
SKJ2-450B	45	500-800	1500	1620x690x1600
SKJ2-550B	55	800-1000	1600	1700x690x1600

Machine's Advantages:
1.SKJ series flat die poultry pellet mill using the high efficiency motor to provide the power, through the cardan connecting the motor and the gearbox or (motor shaft directly connecting with gearbox), big gearbox inside gears big and stron g good for press hard mo lding materials and with big pressure for the machine, working more stableand with long lifetime.
2.Flat die poultry pellet mill motor directly connecting with the machine gears and shaft, also overcome the loose defect of belt connecting as long time using, and stable working.
Application:
Certifications

Factory Tour
Company Profile
Shandong Dexi Machine Co., Ltd Located at Licheng, Jinan, Shandong Province China.We are professional supplier for the biomass pellet machines and complete pellet production line.
Our products involve, wood chipper, wood sawdust making machine, hammer mill, drum rotary dryer, pellet making machine, pellet cooling machine, pellet packing machine and other equipment, such as animal feed pellet line, organic fertilizer pellet making line. We also provide design, technology supports, machine inspection service, etc. Cooperating with different manufacturers and research centers, we provide the pellet making machines with outstanding quality. We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the client's specific requirement, we also accept customize design and machine producing order. Through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill.
Whatever pellet making machine you need from China, contact: Shandong Dexi Machine Co., Ltd. A one stop shop in the middle of China.
Main superiorities 1.Vertical ring die s tructure, feeding vertically, easy heating dis sipation, long time running continually.
2.R ing die fixed, the roller rotates in the ring die, so no deflection, no shaking, machine running more stably.
3.Double layer stainless steel ring die, up and do wn side. One ring die can be using 2 times by turn it over. Cut
down operating costs.
4. With gear box lubricating sy stem and the roller bearing auto lubr icating system, the machine can operating
continuity. (Can 24 hours no stop working )
5. W hole base d as gearbox, inside gears size big, and gear modulus increased , make the gearbox strong and
working stable. We give 3 year guarantee for this type of gearbox. Features 1. The flat-die pellet machine can make pellets without belts driven by the shaft. Using high-tech technology, it is much more advanced than the original belt drive. This machine does not need to add any water to make pellets. It belongs to the one that is dry in and dry out. kind. When manufacturing, we use it for those small-scale farming, and the granules made at the same time can be stored for a long time, and it is not a problem for more than half a year;
2. The flat die pellet machine also plays a sterilizing role in the process of operation. The maximum temperature is 75 degrees, which can kill your microorganisms without affecting the quality of the material;
3. The template and pressure wheel of the flat-die feed pellet machine are made of high-alloy wear-resistant materials, which have the characteristics of long service life, reasonable structure, firmness and durability.

---
