| Operating Weight | 1100kg |
| Digging bucket capacity | 0.025cbm/120kg |
| Digging bucket width | 380mm |
| Rated power | 4kw |
| Main pump | ZANEDA |
| Pump flow | 18L/min |
| MAIN DEMENSIONS | |
| Overall dimension( LxWxH) | 3127x950x2195mm |
| Wheelbase | 920 mm |
| Total length of track on land | 1220mm |
| Platform ground clearance | 380 mm |
| Platform back turning radius | 784 mm |
| Chassis width | 896 mm |
| Track width | 180 mm |
| Chassis ground clearance | 132 mm |
| Track height | 320 mm |
| OPERATING RANGE | |
| Max. Digging depth | 1650 mm |
| Max. Vertical digging depth | 1375 mm |
| Max. Digging height | 2610 mm |
| Max. Dumping height | 1850 mm |
| Max. Digging radius on ground | 2850 mm |
| Min. Rotation radius | 1330 mm |
| Max. Upgrade height of bulldozer blade | 345 mm |
| Max. Digging depth of bulldozer blade | 255 mm |
