Best Price 3.5 Ton Mini Crawler Excavator Mini Digger Swe35UF with 0.05m3 Bucket

Product Description

Product Description
Mini excavator 3 ton hydraulic crawler excavators SWE35UF with EPA CE
SWE35UF hydraulic excavator cooperates with multi-functional working tools to complete tasks such as excavation, loading, leveling,trenching, crushing, drilling, pinching, lifting, etc. It is widely used in the construction and production of hydropower, transportation, municipal, garden, farmland transformation,oil pipelines, etc. Advantages and highlights: 1.More energy-conservation and environmental protection By adopting Yan-mar engine meeting national stage III emission standard, mechanical fuel injection pump has reliable performance. With compact size, the maintenance is convenient. Enough low torque reserve can ensure strong power. High reliability can reduce the maintenance cost. 2.More efficient return Rear-end swing radius adopts tailless design, which can ensure that the tail part will not collide with obstacles under narrow working conditions. Deflectable working device can deflect to left and right at 75° and 50° separately, which can achieve compound action with superstructure. Through swing cooperation with superstructure, digging operation parallel to the wall surface will be achieved and various kinds of working conditions can be coped with easily. 3.More reliable and durable Partial strengthen the parts with great stress on boom and arm, and meanwhile adjust the structure to disperse the stress, which makes the life longer. With standard configured new bucket, the depth of bucket is reduced and unloading material will be faster and easier.
Product Parameters

Type of cab		cabin/canopy
Bucket capacity,std.		m³	0.11
Bucket width		mm	520
Machine weight		kg	3850/3750
Dimensions	Overall length	mm	4890
	Overall height	mm	2555
	Overall width	mm	1700
	Ground clearance	mm	270
Engine	Brand	KU-BO-TA
	Model	D1703-M-DI-EF03
	Displacement	L	1.647
	Output	kW/rpm	18.2/2200
Working ranges	Max cutting height	mm	4925
	Max loading height	mm	3400
	Max digging depth	mm	3120
	Max vertical wall digging depth	mm	2665
	Max digging reach	mm	5390
	Boom swing angle(lef t/right)	°	72/44
	Front swing radius	mm	2263
	Tail swing radius	mm	850
	Max digging force(Arm)	kN	22.5
	Max digging force(Bucket)	kN	31.8
Track	Type		Rubber crawler
	Track Width	mm	300
Undercarrige	Track Length	mm	2163
	Length to center of Rollers	mm	1670
	Lenhth to center of track	mm	1400
	Travelling speed(High/Low)	km/h	4.0/2.3
	Gradeability	deg	30
Swing speed		rpm	9
Ground pressure		kpa	33.99
Dozer size	Width	mm	1700
	Height	mm	366
	Lifting capacity(Height/Depth)	mm	337/376
Hydraulic	Type		1 variable plunger pump
	Displacement	L/min	1*88
	pumps Hydraulic pressure	Mpa	24.5
Fuel tank capacity		L	40
Hydraulic oil tank capacity		L	41

Detailed Photos
