Shd L Biomass Pellet Production Line Wood Pellet Mill

Product Description

Wood Pellet Mill
Discription of wood pellet mill:
The pellets mill is applied to the material with low adhesiveness and low shaping such as the rice husk, sunflower seed husk, peanut shell and other fruit shell branch, trunk, bark, crop straws, rubber, cement ,ash and other chemical materials. The pellet mill is widely used in the feed plant, wood processing, fuel plant, fertilizer plant and chemical plant etc. It is the ideal pressing shaping equipment with low investment and high profit.
SHDwood pellet mill has been successufully applied to the wood pellets production from pinus sylvestris sawdust and other wood scraps/chips/sawdust.
Specifications of wood pellet mill:

model	capacity(t/h)	pellet diameter(mm)	power(kw)	weight(t)	size(mm)
SHD560	1-1.5	4-12mm	90/132	6.1	2600*1300*2300
SHD760	2-2.5	4-12mm	160	7.5	2900*1300*2400
SHD850	2.5-3.5	4-12mm	200	14.5	3300*1400*3100

How to make wood pellets by wood pellet mill:
1. Use Wood Chipper, Wood Crusher to make wood logs, chips (or other materials) smaller. 2. Use Dryer (rotary drum dryer / Air-flow dryer) or add water to the sawdust(or other materials) till its moisture content between 12-15%, which is the best moisture content for pelletizing. 3. Put the sawdust into the pellet machine gradually. Large scale pellet production need a screw feeder to make sure stable feeding of raw material. 4. After pelletized, the pellets are of high temperature that is not suitable for direct packing. So they should be cooled by pellet cooler. Then, pellets go through a vibrating sieve, where good pellets will be left, while broken ones or powder will be collected for reproduction. 5. After all the above procedures, pellets can be packed with a pellet packing machine.
Other products:
Customer cases:
Company Introduction:
We are SHANGHANGDA machinery manufacturing Co., Ltd. One of the first Chinese companies to initiate its own research capabilities in wood pellet mill technology.
We have specialized in this field for 18 years, with strength of Pellet making machine Equipment.The products have been Company products are sold throughout the country, exported to Russia, Southeast Asia, Africa, South America. We got creditable good praise from our customers in many years.
Our Service
1.Quality Warranty
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products.
When yougot the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
You May Have Following Questions:
Q1. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q2: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Notice:All models can be customized according to customer needs.

---
