1000ton Plastic Pallet Injection Molding Machine Factory Price

Product Description

1000ton Plastic Pallet Injection Molding Machine Factory Price
Product Description
SINO-TECH ST-1000A injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-1000A with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features
1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3. Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
Product Parameters

ITEM	UNIT	ST-1000A
INJECTION UNIT
SCREW DIAMETER	mm	100	110	120	130
SCREW L/D RATIO	L/D	24.2	22	20.2	18.6
THEORETICAL SHOT VOLUME	cm³	4083	4941	5880	6901
SHOT WEIGHT99(PS)	g	3715	4496	5350	6280
INJECTION PRESSURE	Mpa	206	171	143	122
THEORETICAINIECTION RATE(PS)	g/s	695	841	1001	1175
PLASTICISING CAPACITY	g/s	96	116	130	148
SCREW TORQUE	N.m	8690
MAX.SCREW ROTATE SPEED	r/min	110
INJECTION STROKE	mm	520
CLAMPING UNIT
MAX.CLAMPING FORCE	KN	1000
MAX.OPENING STROKE	mm	1160
SPACE BETWEEN TIE BARS	mm	1110*1110
MOULD HEIGHT	mm	450-1200
MAX DAYLIGHT	mm	2360
EJECTOR FORCE	KN	245
EJECTOR STROKE	mm	350
EJECTOR QUANTITY	KN	21
OTHER
PUMP MOTOR POWER	KW	90
PUMP PRESSURE	Mpa	16
HEATING POWER	KW	68.45
HEATING ZONE		6
SIZE	m	12.38*2.8*3.5
NET WEIGHT	t	60
OIL TANK CAPACITY	L	1700
INTERNATIONAL DESIGNATION		10000-8410

Detailed Photos

Application
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 1600Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.

Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

---
