| Width | 190,210,230,260,280,340,360(cm) |
| useful reed width | Same as nominal width Max reduction 60cm(190-260cm) |
| Same as nominal width Max reduction 80cm(280-360cm) |
| Speed | 1200 rounds per minute |
| Weft selection | 2c/4c/6c/8c |
| Drive | Superstarting moter |
| Direct drive stop by electromagnet brake |
| Weft insertion | Main and sub-nozzles combined system |
| Auxiliary main nozzle |
| Profiled reed |
| Shedding | Positive cam: shaft up to 10 |
| Dobby: shaft up to 20 |
| electronic jacquard φ800mm |
| Let-off Flange Dia | Servo electronic let-off |
| Positive easing |
| Servo electronic take-up |
| Take up Max take up Dia. | φ600mm |
| Take up Pick density | 9.8-118 picks/cm |
| Take up Length count | board dispiay. fixed meassure stop |
| Take up Side brace | overhead |
| Beating | Crank beating |
| 4 links(Read space 190-280cm) |
| 6 links(Read space 280-360cm) |
| intermediate rocking supporter |
| Filling Supply Stand | Floor-mounted for 4packages(2c), for8 (4c)for10(6c) |
| Cutter | Mechanical cutter |
| Lubrication | Oil bath system for main drive parts, centralized lubrication(manual grease) |
| Auto stop Motion Weft broken | Reflective weft feeler |
| Auto stop Motion Warp broke | Six rows Electric fleeling system |
| Others | Stop for selvage and catch cord yarn |
| Stop cause indication | Message on board, 4-colors lamp for indicating cause |
| Middle scissors | Mechanical type(Tisser double width) |
