| Technical Data Sheet for Diesel Engine(R4105P) |
| Engine model | R4105P |
| Bore x stroke(mm) | 105×125 |
| Displacement(L) | 4.33 |
| Compression ratio | 17：1 |
| Under the standard conditions | 15 Min, Power(KW/RPM) |
|
| 1 Hour Power(KW/RPM) |
|
| 12 Hours Power(KW/RPM) | 48/2000 |
| Maximum non-load speed(RPM) | 2160 |
| Minimum idling stabilized speed(RPM) | 600 |
| Under the standard conditions | Mean effective pressure(Kpa) | 665 |
| Fuel consumption(g/kw.h) | 239 |
| Oil consumption(L) | 1.63 |
| Discharge temperature(℃) | 600 |
| Injection timing | 15-19 |
| Net weight（KG） | 550 |
| Engine dimensions(mm) | 1461×831×1328 |
| Oil sump capacity(L) | 13 |
| Charging alternator-voltage/power(V/W) | 28/350 |
| Starter motor-voltage/power(V/KW) | 24/5 |
| Clutch | R1P750000 |
