Slant Bed CNC Horizontal Metal Lathe Machine Tck500gp CNC Turning Center

Product Description

Product Description
Products Description:
Slant Bed CNC Horizontal Metal Lathe Machine Tck500gp CNC Turning Center
Performence Features:
This series of machine tools uses a 30° inclined overall bed, and the bed material is HT300. Using resin sand art casting, internal
The rib layout is reasonable. The guide rail adopts imported linear roller guide, which has improved feed accuracy, low friction resistance, good rigidity, and
Vibration and deformation resistance is high, allowing users to obtain higher accretion accuracy and faster moving speed, and obtain higher
Production efficiency.
Higher accuracy Taiwan Linear guideways.
High speed spindle unit.
Higher rigidity cast iron.
Integrated automatic lubrication
30 degree One-piece casting slant bed.
Technical parameter:

Specifications	Unit	TCK500GP
Max.swing over bed	mm	560
Max. turning diameter	mm	400
Max.swing over cross slide	mm	330
Max. turning length	mm	750
Spindle nose	A2	A2-6
Chuck size	Inch	8''
Spindle motor power	kw	11/15
Max.spindle speed	rpm	4200
Spindle bore	mm	79
Max.bar dia. through spindle hole	mm	65
Bed slant angle	Degree	30°
X/Z axis leadscrew diameter	mm	32/40
X/Z axis linera guideway width	mm	45/45
X axis limit Travel	mm	270
Z axis limit Travel	mm	830
X/Z axis motor torque	Nm	12/22
X/Z axis motor power	kw	1.8/3.0
Tailstock travel	mm	750
Tailstock quill travel	mm	80
Tailstock quill diameter	mm	80
Tailstock taper	Morse	MT5
Machine weight	kg	4100

Standard accessories

Fanuc 0i TF plus controller

Main motor and servo motor from Fanuc

Linear guideway from THK

Ball leadscrew from THK

Hollow hydraulic chuck

Foot switch for chuck clamp and tailstock

Tool measurement probe Renishaw

Hydraulic programmable tailstock

Hydraulic stations

Hydraulic turret 12 tools

6 tool seat (2 external,2 internal,2 boring)

Telescopic covers

Full closed cover

Coolant system

Lubricating system

Work lamp

Tri-color alarm lamp

Safty door

USB interface

Chain type chip conveyor

Air gun + Water gun

Siemens electric components

Live center

Tools and tool box

English Manual

Optional accessories

Power turret BMT55

Extra Radial live head

Extra Axial live head

C axis Function

Y axis travel ±45mm

Part catcher

Servo type bar feeder
