| MIG-200I CHEAP PORTABLE MIG WELDING MACHINE |
| ITEM | MIG-200I |
| Input Power Voltage | AC230V |
| Input Power Frequency | 50/60HZ |
| Rated Input Capacity | 6.1KVA |
| Mig Output Current Range | 180A |
| Rated Duty Cycle | 60% |
| Gas flow | 15-20L/min |
| Wire Feed Speed | 3-15M/min |
| Load Voltage | 16-24V |
| Dimensions | 510x275x450mm |
| Net weight | 25KG |
(1)Advanced IGBT inverter technology,cost saving and energy improving.
(2)PWM control,high quality and stable performances.
(3)Slow wire feeding,tip ball removing, electronic induction regulating and shielding gas post-flow function .
(4)Accurate current control,stable arc transition,and excellent welding characteristics.
(5)Automatic over-voltage and over-current protection protects main components from potential damage and reduces costly repairs.
(6)Built-in wire feeder;easy to carry around.
(7)Supplied with MIG gun,earth clamp,welding cable,face mask and welding brush.Gas regulator
optional.
ITEM
| UNIT
| MIG-200I
| MIG-250I
| MIG-270I
|
Input power voltage
| V
| AC220V
| AC220
| AC400
|
Input power frequency
| HZ
| 50/60
| 50/60
| 50/60
|
Rated input capacity
| KVA
| 6.1
| 8.4
| 9.4
|
Output current range(MIG)
| A
| 180
| 200
| 240
|
load voltage
| V
| 16-24
| 16-26.5
| 16-27.5
|
Wire feed speed
| M/min
| 3-15
| 15-20
| 15-20
|
Gas flow
| L/min
| 15-20
| 15-20
| 15-20
|
Rated duty cycle
| %
| 60
| 60
| 60
|
Dimensions
| mm
| 510x275x450
| 510x275x450
| 510x275x450
|
Weight
| kg
| 25
| 25
| 27
|
3m MIG Torch1.2m earth clamp Mask and brush Gas Meter
MIG-200PI MIG-200EMIG-205A MIG-200U
