Low price sauce pasteurization machine

Product Description

Product Description
Company Information
Product Description
Low price sauce pasteurization machine
GYC small liquid milk pasteurizer pasteurization machine
Product Detail

Capacity	20-150L/H
Material	Stainless steel 304
Circulating pump power	0.37KW, the cycle time can be timed
Application	Milk, soy milk, beer, liquid, etc.
Pipeline filter	filtration accuracy 120~300 mesh optional.
Heat transfer pipe diameter	19mm
Cooling Water Consumption	200-350L / H
Heat Exchange Area	1.85 Cubic Metre
Germicidal Temperature	75~90 Centigrade
Product Keywords	sauce pasteurization machine

Scope of use
This equipment is widely used in raw milk, soy milk, bio pharmaceutical, bean products, liquid condiments and other materials to determine and update raw materials, product taste identification, color evaluation, stabilizer / emulsifier application, new product research and development and batch production of pasteurized milk products. This production pasteurizer is integrated with heating, sterilization, cooling and hot filling. It is an ideal set of equipment for small pasteurized milk enterprises in schools and communities.
Machine features
The sterilization temperature of the equipment can be set according to the requirements of pasteurization or high temperature sterilization. The equipment adopts casing sterilization, the area of heat transfer is large, the heat exchange rate is fast, and the sterilization temperature of the equipment can be adjusted at 62 degree C~85 C. All the equipment in contact with the product are made of SUS 304 stainless steel. The pipe washer and seal are made of polytetrafluoroethylene with food grade. The product line is connected to the DIN pipe connector. In the display output, the production pasteurizing machine is equipped with digital display temperature control system and timing sterilization control system, and can select the sterilization temperature and time as well as the clearance time of the pump cycle time according to the user's requirements. The equipment is a multi tank combined structure, which is very suitable for small batch and multi variety production.Genyond small camel milk pasteurizer price
The equipment occupies an area of only 2 square meters, with a miniature superheater generator and no external steam generator or steam boiler. According to actual needs, the PID constant temperature control technology can be regulated in real time, so that the whole temperature zone temperature control is accurate, and the sterilization temperature control accuracy is + 1 degrees Celsius. The equipment has its own pipeline and tank cleaning circulating pump, which can automatically clean the sterilization pipes and valves. A built-in micro water heater. Built in PT100 temperature sensor. All closed structure with hygienic test.
Transport way
Machine production process
Certificate
FAQ
Target market
Contact Us
Company Profile
Shanghai Genyond Technology Co., Ltd.
Shanghai Genyond Technology Co., Ltd. is a manufacturer of extracting unit and fruit & vegetable processing line with well-equipped testing facilities and strong technical force.With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food and beverage and other industries.Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
