11kv 0.4kv 2000kVA Stabilizer Step up High Voltage Oil Immersed Power Transformer

Product Description

Product Description
Introducing the epitome of modern energy solutions - our high-efficiency oil-immersed transformer. This marvel of energy-savings technology elegantly intertwines with ecological responsibility, offering an unrivaled experience in power transformation. By masterfully utilizing oil as both an insulating and cooling medium, this exceptional transformer elevates power conversion and heat dissipation performance to unparalleled levels. Crafted for excellence, these indispensable transformers play a pivotal role in power transmission and distribution systems, meticulously engineered to dramatically reduce energy consumption, amplify grid efficiency, and significantly trim down environmental impacts. Key Features 1. Energy Efficient: This transformer features an ingeniously optimized design that dramatically curtails core and coil losses, resulting in a substantial leap in energy conversion efficiency and effectively curbing operational energy consumption, thus offering remarkable savings. 2. Low Loss: Crafted from top-tier silicon steel sheets through innovative manufacturing techniques, it skillfully reduces both no-load and load losses, thereby significantly decreasing overall operating costs in the power system. 3. Excellent Heat Dissipation: Leveraging oil as a cooling medium, it achieves outstanding heat dissipation through either natural convection or forced oil circulation, ensuring stable operation even under intense load conditions, thus extending the equipment's operational life. 4. Environmentally Friendly Design: In harmony with both national and international energy conservation standards, this innovative design drastically reduces carbon emissions and mitigates environmental pollution, making it an exemplary choice for green energy initiatives and modern eco-conscious power grids. 5. Safe and Reliable: The synergy of high-strength insulation materials with precision engineering assures safe and steadfast operation even in the most challenging grid environments.
Product Parameters

Product Model	Rated Capacity(kVA)	Connection Group	No-Load Loss	Load loss(W)(120°)
S11-M-50/35	50	Yyn0 Dyn11	160	1200/1140
S11-M-100/35	100		230	2010/1910
S11-M-125/35	125		270	2370/2260
S11-M-160/35	160		280	2820/2680
S11-M-200/35	200		340	3320/3160
S11-M-250/35	250		400	3950/3760
S11-M-315/35	315		480	4750/4530
S11-M-400/35	400		580	5740/5470
S11-M-500/35	500		680	6910/6580
S11-M-630/35	630		830	7860
S11-M-800/35	800		980	9400
S11-M-1000/35	1000		1150	11500
S11-M-1250/35	1250		1400	13900
S11-M-1600/35	1600		1690	16600
S11-M-2000/35	2000		1990	19700
S11-M-2500/35	2500		2360	23200

Products advantages: Oil-immersed transformer
Providing bespoke customization services tailored to meet diverse client requirements
Exceptional insulation and heat dissipation capabilities
Boasting minimal no-load losses, exceptionally low noise levels, and a prolonged service life. Certifications
Company Profile
FAQ 1. What about the lead time?
Firstly, let us know your requirements or application.
Secondly, we quote according to your requirements or our suggestions.
Thirdly, customer confirms the samples and places deposit for formal order.
Fourthly, we arrange the production.
2. Can you do OEM?
Yes, we are 61 years factory,we can provide OEM (Original Equipment Manufacturer) services. We can customize the transformers according to your specifications, including branding, design, and packaging to meet your specific needs. Let us know your requirements, and we'll work with you to deliver a product that aligns with your request. 3. What is your payment terms?
T/T, L/C,Visa Paypal for different circumstances. 4. Do you have inspection procedure before shipping?
Yes,we do 100% QC inspection. 5. Do you offer guarantee for the products?
Yes. We offer at least two years warranty for all of our transformer.

---
