Plastic Waste Recycling Equipment with Enhanced Washing and Crusher System

Product Description

State-of-the-Art Plastic Recycling Washing Line: Proudly presented by Wenzhou Wandun Machinery Co., Ltd., our cutting-edge PE Plastic Recycling Machine with Enhanced Washing Line is meticulously engineered to deliver unmatched efficiency in the granulating process. Revel in superior performance and unwavering reliability, perfectly tailored to meet and exceed all your plastic recycling requirements.
Product Description
The plastic recycling washing system stands as a pivotal element within Kitech machinery's renowned recycling series. This brilliantly conceptualized and modular system is expertly designed to adeptly handle rigid plastics and bottles. It proficiently processes a wide array of plastics such as PE, LDPE, HDPE, PC, PS, and ABS, ensuring superior soft recycling.
Kitech provides customizable module combinations specifically crafted to meet your precise requirements and material conditions. With the versatility to manage a broad spectrum of raw materials, Kitech offers production lines ranging from 300 to 10,000 Kg. Choose from economy to high-level configurations to perfectly align with your production needs.


Introduction:

Type	WT500	WT100	WT2000	WT3000
Capacity(kg/h)	400-500	800-1000	1600-2000	2500-300
Dimension(L*W*H)	35*10*5	50*12*6	70*12*6	120*20*6
Steam consumption(kg/h)	0-150	0-200	0-300	0-600
Chemical consumption(kg/h)	0-3	0-5	0-10	0-20
Energy consumption(kwh)	175	198	306	550
instalation power(kwh)	210	330	498	810
*** (person /shift)	3-5	3-8	3-10	3-12

Main Technical Variables:
Belt conveyor:
Constructed as a heavy-duty type, equipped with a robust gear motor;
Features side walls designed to prevent material spillage;
Crusher:
Precisely engineered with sharp and powerful blades;
Enclosed cutting chamber to securely contain materials;
Externally adjustable knives for user convenience;
Shredder:
Specially designed hopper to prevent material ejection;
Equipped with four-way rotating knives featuring unique holders;
Boasts extremely robust pedestal bearing housings;
External mounting of bearing pedestal designs;
Screw conveyor:
Crafted with wear-resistant stainless steel screws;
Features triple sealing with external bearing design;
Washing tank:
Includes a double station discharge valve positioned at the bottom;
Offers variable speed control via inverter;
Heavy-duty washing unit, enabling effective separation of materials with varying densities;
Friction washer:
Constructed with a rotor and blades made from wear-resistant steel;
Rotor with dynamic balance treatment, attaining an accuracy of ±3-5g;
Active material washing to protect downstream units;
Centrifugal dryer:
Rotor with dynamic balance treatment, ensuring an accuracy of ±3-5g;
Equipped with a mild circular screen designed in a four-piece polygon configuration;
The washer/dryer housing is constructed with stainless steel welded construction;
Squeezing dryer:
Features a heavy-duty shaft and blade;
Equipped with double hydraulic press units;
Motorized screw squeezing mechanism;
Hot air pipe dryer:
Pipeline constructed with stainless steel welding;
All material-contacting parts are made from stainless steel;
Hot air drying system for optimal drying efficiency;
Storage buffer:
Designed to be directly connected with the pelletizing process;
Large storage capacity ensures uninterrupted operation;
Electrical cabinet:
Equipped with internationally recognized brand low voltage components;
Features a double circuit safety relay for enhanced protection;
Intelligent and modular PLC controlling system for seamless operational efficiency.
Q1. What are your terms of packing?
A: Our standard packaging involves placing the machine on a protective pallet and securely wrapping it with plastic film to ensure safe transportation.
For our esteemed European clientele, we rigorously ensure that wooden boxes are meticulously fumigated to guarantee safe and compliant transportation. Our packing process is thorough, utilizing premium PE film for added protection. Moreover, we offer bespoke packing solutions, customized to meet the unique requirements of each of our valued customers.
We are fully equipped and highly adaptable to accommodate any special requests, ensuring that we meet your specific needs and preferences with precision.
Q2. What are your payment terms?
A: Our payment terms are designed for clarity and convenience: a 30% deposit via T/T is required upfront, with the remaining 70% payable before delivery. To maintain transparency, we provide detailed photographs of the products and their packaging prior to the final payment, assuring you of the quality and condition of your order.
Q3. What are your delivery terms?
A: We offer a variety of flexible delivery terms including EXW, FOB, CFR, and CIF, designed to accommodate your unique logistical needs and preferences.
Q4. What is your delivery timeframe?
A: Typically, our delivery timeframe ranges from 30 to 60 days following receipt of your advance payment. The exact timeframe may vary depending on the specific items and the quantities ordered, ensuring each order meets your precise requirements.
Our delivery times are adaptable and may vary based on the specific details and specifications of your order, providing the flexibility you need.
Q5. Do you test all your products before delivery?
A: Absolutely, we undertake a comprehensive 100% testing process on all our products to guarantee they meet our rigorous high-quality standards before delivery, ensuring your utmost satisfaction.
Q6: How do you ensure long-term and positive business relationships?
A: 1. We consistently deliver premium-quality products at competitive prices, maximizing value and satisfaction for our customers.
2. We treat every customer with the highest level of respect, fostering genuine and enduring business relationships and friendships, irrespective of their background or origin.

---
