| US$13,900.00 | 1 Piece (MOQ) |
| Main Specifications and Technical Parameter | ||
| ltem | MA1420E | MA1420E/750 |
| Grinding diameters | 8~200 mm | 8~200 mm |
| Grinding bores | 13~80 mm | 13~80 mm |
| Max grinding length | 500 mm | 750 mm |
| Max grinding depth | 125 mm | 125 mm |
| Max trabel of table | 600 mm | 800 mm |
| Hydraulic traverse speeds | 0.1~4 m/min | 0.1~4 m/min |
| Swivel range of the table | -5°~+9° | -3°~+9° |
| Max peripheral speed of grinding wheel | 37 m/s | 37 m/s |
| Wheel dimensions | 300x40x127 | 300x40x127 |
| Speeds of headstock spindle | 60,85,120,170,230,460 r/min | 60,85,120,170,230,460 r/min |
| Coolant pump drive motor | 8 KVA | 8 KVA |
| Overall dimensions(LxWxH) | 2000x1420x1600 mm | 2700x1420x1600 mm |
| Weight of machine | 2100 kg | 2600 kg |
| Work precision | ||
| ltem | MA1420E | MA1420E/750 |
| Ex Ternal | 1.5 um | 1.5 um |
| In Ternal | 2.5 um | 2.5 μm |
| Cylindricity | 5 um | 5 um |
| Ex Surface | Ras0.32 um | Ras0.32 um |
| In Surface | Ras0.63 um | Ras0.63 um |
| Main accessories | ||
| 1 | Coolant tank | 1 set |
| 2 | Open center rest | 1 set |
| 3 | Grinding wheel dresser | 1 set |
| 4 | Grinding wheel clamp | 2 sets |
| 5 | Grinding wheel balancer | 1 pc |
| 6 | Carbiede-tipped center | 2 pcs |
| 7 | Half center | 2 pcs |
| 8 | Chuck | 1 set |
| 9 | Hexagon socket wrench | 1 pc |
| 10 | Vblet | 2 pcs |
| 11 | Support iron | 3 pcs |
| 12 | Dismountingnut | 1 pc |
| 13 | Three jaw chuck | 1 set |
| 14 | Closed center rest | 1 set |
| 15 | Grinding wheel arbors for internal grinding | 4 sets |
