Double Work Station Full Automatic Paper Plate Making Machine

Product Description

JNZD-D Automatic Rolling & Feeding Paper Plate Machine Product Description JNZD-D Automatic paper plate machine is independently developed and designed according to the needs of the market, with automatic servo motor roll paper feed, automatic die cutting, automatic indentation, heating molding, automatic disc and constant temperature control, automatic counting, automatic collection, counting and other functions. It is the ideal equipment for the production of various sizes of round paper plates, square paper plates and shaped paper plates.
Machine compared with the traditional automatic paper machine, it recombines the principle of mechanical and hydraulic combination, and has the advantages of better production efficiency, more stable performance, safer operation, more convenient maintenance and more user-friendly structural design.
Machine is widely used in the production of paper or aluminum foil as raw materials of the plate. By changing the mold can produce different specifications, different shapes of round or square plate.
Product Parameters

HS.code	8441309000
Machine Size:	(L x W x H): 4300mm x 1250mm x 2000mm ;
Weight:	1600kgs
Plate Size	5-11 inch (molds exchangeable)
Speed :	60-80pieces/min (total two working stations).
Material :	Paper/paperboard, Single Aluminum-foil/film coated paper or other (150 -- 400gsm);
Heating power	4KW
Motor Power:	8.5KW,
Voltage	380V / 50Hz
Air source :	Working pressure 0.8Mpa, working air volume 1m3/minute; Should buy air compressor.

Detailed Photos

---
