| Model | VMC850 (GSK25i system) | VMC 1050(GSK25i system) |
| Travel parameters of 3 axis | | |
| X /Y/Z axis travel | 800/500/500mm | 1050/500/500mm |
| Spindle nose to table surface | 120-620mm | 120-620mm |
| X/Y/Z axis AC servo motor | torque N.m 15/15/22 | torque N.m 15/15/22 |
| Spindle center to column surface | 550mm | 550mm |
| Worktable | | |
| table size | 1000×550mm | 1000×550mm |
| Max.loading | 600kg | 600kg |
| T Shot | 5×18×90mm | 5×18×90mm |
| Feeding parameters | | |
| X/Y/Z axis rapid feed | 24/24/20m/min | 20/20/18m/min |
| Cutting feed | 1-10m/min | 1-10m/min |
| Spindle parameters | | |
| Main shaft connection | Belt | Belt |
| Spindle taper | BT40-140 | BT40-150 |
| Range of spindle speed | 8000rpm | 8000rpm |
| Spindle motor | 7.5kW | 7.5kW |
| ATC paremeters | | |
| ATC capacity | 24qty | 24qty |
| Max.tool dia | Φ80/Φ150mm | Φ80/Φ150mm |
| Max.tool weight | 8kg | 8kg |
| Precision | | |
| Position accuracy(JIS standard) | ±0.008/300mm | ±0.008/300mm |
| Repeat positioning accuracy(JIS standard) | ±0.005mm | ±0.005mm |
| Shape and weight | | |
| Dimensions | 2750×2300×2300mm | 2800×2360×2450mm |
| Weight | 5200kg | 5600kg |
