Electroplated abrasive belts

Product Details

Product Description

Product Description
Brief Introductions:

Type:	Band Saw Blade
Bond:	Electroplated
Application:	Polishing, grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum magnesium alloy, aluminum beryllium alloy, titanium alloy and etc.
Specification:	Customized
Brand Mark:	Moresuperhard
Trade Terms:	FOB
Packages:	Hard carton
Delivery Time:	15 workdays by express

Introductions of Moresuperhard’s Electroplated abrasive belts
Diamond sanding abrasive belt is a kind of coated abrasive tool, which is super hard material (synthetic diamond) abrasive particles adhesive to the flexible base by bond. And can be divided into metal nickel plating electroplated bond and resin bond, resin bond also consists flexible and hard type. In some sense The grinding by diamond sanding belt for thermal spray coating industry can replace that of diamond grinding wheel and film polishing. Diamond sanding belt can complete the grinding and polishing process. Recently, it is widely used in thermal spray coating industry, the production and repair of hydraulic cylinder and turbine blade.

Length		Width		Girt
(mm)	(inch)	(mm)	(inch)	#60,#100,#120, #200, #400, #800, #1500, #2000, #3000, #5000
150 – 5000	6” – 200”	5 – 350	1/5 “ – 14”

Detailed Specifications can be customized!
Advantages of Moresuperhard’s Electroplated abrasive belts* More embedding depth, less exposure
* Grinding belt does not move parts
* Shortcomings: diamond particles are easy to fall off, do not require grinding allowance.
* Wet grinding effect is good
Examples:

Workpiece diameter	400mm*12 HVOF spraying
Grinding machine model	65656
Belt speed	22 m/s (2800rpm)
Belt contact workpiece mode	soft contact or hard contact
Workpiece rotation speed	30 RPM
Coolant	water or others
Spray coating thickness	250μm
Original roughness of spray coating	Ra 0.4mm-0.6mm
Machining allowance of spray coating	100μm
Coating thickness after processing	150μm

---
