Manufacturer High Quality Hot DIP Galvanizing Lines Steel Coil Zinc Coating Machine Production Line

Product Description

Manufacturer High Quality Hot Dip Galvanizing Lines Steel Coil Zinc Coating Machine Production Line
Color coated aluminum coil, which was finished through degreasing, cleaning, passivation, coating and baking, are mainly used in fields of construction decoration such as aluminum composite panel and ceiling etc..
Application of Product and characteristics:
1,Coating thickness is stable by using rolling coater
2,The paint can be PVDF, PE and AC 3, With multi-module PLC control system 4, Heating and drying system and drying system with natural gas or diesel oil
Coil parameter

1	/Matierial	SPCC
2	/Thinkness	0.16-1.2 mm (os≤300Mpa,ob≤300Mpa)
3	/Width	800-1250mm
4	/Coilinside diameter	Φ508mm
5	/Coilousiade diameter	≤Φ1800mm
6	/Coil weight	Max15T

Product parameter(Coating)

1	/Galvanizing		Double side(Once)
2	/Galvanizing thickness		30~275g/m2(Double side)
3	/Running Control		Automatic
4	/Products width	800-1250mm
5	/Decoil inner diameter	Φ510mm

Machine parameter

1	/Speed	0-100m/min
2	/Power	Around 1800KW
3	/Direction	/By buyer
4	( Size)	Around 180mx12m(L*W)
5	/Source	AC 3×380V10%,60Hz±2%
6	/Compressed air	0.4-0.8Mpa, 1000L/min
7	N46/Hydraulic oil	500L/By buyer
8	/Color	/By buyer
9	Gas	LPG or LNG/By buyer
10	Pure water	/By buyer
11	/Ammonia	/By buyer

Description:

1	/Uncoiler	2set	Hydraulic
2	/Support	2set	Hydarulic
3	/Coil car	2set	Hydraulic
4	/Roller Feeder	2Set	2 rollers
5	/Joint Welding Machine	1Set	Semi-automatic
6	/EPC machine	1Set	Servo Hydraulic
7	/CPC machine	11Set	Servo Hydraulic
8	/Tension Machine	8set	Inventor control
9	/Cutter	2set	Electric
10	/Sheet storage	2set	240M
11	+/Degreasing &Washing section	1set	1-stage chemical degreasing + brush roll degreasing + 3-stage water rinsing. The shed body is of stainless steel structure, with stainless steel spray pipe / nozzle / pipeline; Circulating tank: 4 alkali + 3 water washing, stainless steel structure, with external insulation, anti-corrosion pump, annealing furnace waste heat heating tank liquid
12	/Annealing furnace	1set	Horizontal structure, 35 gas radiant tubes, W-type, made of cr25ni35 / cr25ni20, with a total length of 70m, including radiant tube heating section, insulation section, cooling section, equalization section, etc. Multi zone furnace temperature control. 1 set of hydrogen, oxygen and dew point analyzers respectively, 4 sets of fast cooling fans, frequency conversion
13	/Tension bending Straightener	1set	2Bending & 2Straightening
14	/Zinc Pot	2set	Induction heating ceramic zinc pot, 160 tons of pure zinc; Induction power: 2 × 400Kw
15	/Air knife and support	1set	Include 1set Air Knife, pedestal and control system
16	/Blower for Air knife	1set
17	/3 roller & 6 arm	1set

18	/Cooling part	7set
19	/Decoiler	1set	Inventor control,Max120m/min
20	/Support	1set	Hydarulic
21	/ Quenching tank	1set
22	/Tension detection	1set
23	/Cooling turner roller	1set
24	/Turner roller	1set
25	/Steel platform	1set	By buyer
26	/Cooling steel paltform	1set	By buyer
27	/Plate car	1set	Out-in by motor on the track
28	/Hydraulic pressure station	2set
29	/Control system	1set	PLC control
30	/Roller light machine	1set	Option
31	Oil machine	1set	Option
32	Passivation part	1set	Option

Manufacturing Technique
Parameters

Qiangda120
Model	Sheet Thickness(mm)	Width(mm)	No. of Slitting	Tolerance	Speed	Coil Weight(T) max
120-1x650	0.2-1	150-650	30-8	±0.05	0-120	3,5
120-1x850	0.2-1	300-850	30-8	±0.05	0-120	5,10
120-1x1050	0.2-1	300-050	30-8	±0.05	0-120	5,10
120-1x1300	0.2-1	400-1300	30-8	±0.05	0-120	10,15
120-2x650	0.3-2	150-650	30-8	±0.05	0-120	3,5
120-2x850	0.3-2	300-850	30-8	±0.05	0-120	5,10
120-2x1050	0.3-2	300-1050	30-8	±0.05	0-120	5,10
120-2x1300	0.3-2	400-1300	30-8	±0.05	0-120	10,15
120-2x1600	0.3-2	400-1600	30-8	±0.05	0-120	15,20
120-2x2000	0.3-2	500-2000	30-8	±0.05	0-120	15,20
120-3x1300	0.4-3	400-1300	30-6	±0.05	0-120	10,15
120-3x1600	0.4-3	400-1600	30-6	±0.05	0-120	15,20
120-3x2000	0.4-3	500-2000	30-6	±0.05	0-120	15,20
120-4x1300	0.5-4	400-1300	30-6	±0.05	0-120	10,15
120-4x1600	0.5-4	400-1600	30-6	±0.05	0-120	15,20
120-4x2000	0.5-4	500-2000	30-6	±0.05	0-120	15,20
120-6x1600	0.6-6	400-1600	30-5	±0.08	0-120	15,20
120-6x2000	0.6-6	500-2000	30-5	±0.08	0-120	15,20
Qiangda200
Model	Sheet Thickness(mm)	Width(mm)	No. of Slitting	Tolerance	Speed	Coil Weight(T) max
200-1x650	0.2-1	150-650	30-8	±0.05	0-200	3,5
200-1x850	0.2-1	300-850	30-8	±0.05	0-200	5,10
200-1x1050	0.2-1	300-050	30-8	±0.05	0-200	5,10
200-1x1300	0.2-1	400-1300	30-8	±0.05	0-200	10,15
200-2x650	0.3-2	150-650	30-8	±0.05	0-200	3,5
200-2x850	0.3-2	300-850	30-8	±0.05	0-200	5,10
200-2x1050	0.3-2	300-1050	30-8	±0.05	0-200	5,10
200-2x1300	0.3-2	400-1300	30-8	±0.05	0-200	10,15
200-2x1600	0.3-2	400-1600	30-8	±0.05	0-200	15,20
200-2x2000	0.3-2	500-2000	30-8	±0.05	0-200	15,20
200-3x1300	0.4-3	400-1300	30-6	±0.05	0-200	10,15
200-3x1600	0.4-3	400-1600	30-6	±0.05	0-200	15,20
200-3x2000	0.4-3	500-2000	30-6	±0.05	0-200	15,20
200-4x1300	0.5-4	400-1300	30-6	±0.05	0-200	10,15
200-4x1600	0.5-4	400-1600	30-6	±0.05	0-200	15,20
200-4x2000	0.5-4	500-2000	30-6	±0.05	0-200	15,20
200-6x1600	0.6-6	400-1600	30-5	±0.08	0-200	15,20
200-6x2000	0.6-6	500-2000	30-5	±0.08	0-200	15,20

Installed for customers on site
Application of Products
Cooperation Brand
Delivery & Shippment
FAQ
Q: What information do I need to provide Qiangda Company to have a set of equipment quoted?
A: Qiangda&Yuao technical department will design and drawing mechanical equipment according to the customer's requirements for the product.The sales department will quote production line and spare parts according to the requirements of the drawings.
Q:If I don't see the machine I need in the Geartech catalog or on the website, can I inquiry about a totally custom machine?
A: Qiangda&Yuao specializes in custom machine solutions. Our R&D department professionals work with customer's needs to supply a custom solution for their project.
Q: How does the machine sign-off, shipping and installation work?
A: Qiangda&Yuao has nearly 20 dispatched engineers who are on standby to go to the customer's factory for installation, commissioning and maintenance. It usually takes 30 days to stay there. We will also teach factory workers the correct use of machinery and equipment, simple maintenance and other skills.

---
