100-2000kg/H Waste Glass Fiber Carbon Fiber Aramid Fiber Pulverizer Machine

Product Description

100-2000kg/h Waste Glass Fiber Carbon Fiber Aramid Fiber Pulverizer Machine
Application:
Fiber Reinforced Polymer or Fiber Reinforced Plastic(FRP)is formed by reinforced fiber material, such as glass fiber, carbon fiber, aramid fiber, etc., and matrix material through winding, molding or pultrusion and other molding processes composite material. According to the different reinforcing materials, common fiber reinforced composites are divided into glass fiber reinforced composites (GFRP), carbon fiber reinforced composites (CFRP) and aramid fiber reinforced composites (AFRP).
Because fiber-reinforced composite materials have the following characteristics: (1) high specific strength and specific modulus; (2) material properties are designable: (3) good corrosion resistance and durability; (4) thermal expansion coefficient and concrete similar. These characteristics enable FRP materials to meet the needs of modern structures to develop large spans, high towers, heavy loads, light weight and high strength, as well as the development of work under harsh conditions, and also meet the requirements of the development of modern building construction industrialization, so they are more and more widely used. It is used in various civil buildings, bridges, highways, oceans, hydraulic structures and underground structures.
Description:
The disc grinding pulverizer machine of the PNMF series are available with disc diameter from 300 to 800 mm. These plastic pulverizer machines are high speed, precision grinders for the processing of medium hard, impact resistant and friable materials. The material to be pulverized is introduced through the centre of a vertically fixed grinding disc which is mounted concentrically with an identical high speed rotating disc. Centrifugal force carries the material through the grinding area and the resulting powder is collected with a blower and cyclone system. Depending on the application the machines can be equipped with one piece grinding discs or grinding segments.
The plastic pulverizer machine is mainly composed of electric motor, disc type blade, feeding fan, vibrating sieve, dust removing system, etc.
According to the customer's needs, you can choose some accessories, such as converter, vacuum loader, screw loader, magnetic net, metal separator, chiller, pulse dust collector, metering and weighing packaging machine, etc.
Components:
Technical Features:
1. The new disc design is with high quality, strong resistance and the life of this grinding disc is double the ordinary ones.
2. The newly designed professional bearings, is with a high rotation rate. At the same time using only one drive motor, to ensure the efficient grinding crash, which greatly saves the time of machine operation and engineering control.
3. Easy installation and maintenance, just open the door to clean up.
4. The whole milling process is sealed, without dust leakage.
5. Full automatic design, automatically feeding, discharging and sorting.
6. Grinding gap adjustment is simple, just use the feeler gauge and adjust bolts can be fine tuning.
7. The mill use the water and wind double cooling system ,Prevent bearing and other parts from overheating.
8. Using Well-known brand accessories, such as Siemens motors, can work for a long time, saving the trouble of changing accessories frequently.
9. With a wide range of optional accessories, professional solutions can be developed based on the customer's budget and processing requirements.
Specifications:

Model	PNMF-300	PNMF-400	PNMF-500	PNMF-600	PNMF-800
Disc Diameter(mm)	300mm	400mm	500mm	600mm	800mm
Dimension L*W*H(mm)	3700*1500*3700	3800*1600*3800	3900*1700*3900	4000*1800*4000	4300*1900*4300
Main Motor(kw)	11-15	22-30	30-37	45-55	75-90
Air Blower(kw)	3	4	5.5	5.5kw	7.5
Vibrating Motor (kw)	0.55	0.55	0.75	1.1	1.1
Air Lock Motor (kw)	0.75	0.75	0.75	0.75	0.75
Capacity (kg/h)	30-50	50-120	120-200	200-350	400-600

Customer Feedback:
Our Service
1. One year guarantee for the whole machine
2. 24 hours technical support
3. Our engineers can provide services overseas. The service is free, but the charge of round air-tickets, food, and the hotel is to the customer's account.
4. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price.
5. We also can provide training service which help operators handle the machine well.

---
