High-Density Polyethylene Pipe for Cold & Hot Water & Electric Conduit Pipe Sch40 Sch80 Plastic Pipe Corrugated /PVC-U/Mpp/PPR/Hard Plastic/ Sotcket Pipe 6m 12m

Product Description

Product Name	Factory Outlet Large Diameter 315mm 350mm 400mm 600mm 630mm PVC Plastic Pipe Price
Material	Polyvinyl chloride
Color	White Grey or customized
Standard	GB/T 5836.1-2006
Length	4m 6m or 12m or as required
Feature	corrosion resistance and pressure resistance
Application	Water supply, irrigation and drainage

(DIN Standard,DIN8061,DIN 8062 )UPVC Pressure pipe for water supply PVC Pipe Drinking Water
nominal outside diameter dn	S series SDR series and nominal pressure
	S16	S12.5	S10	S8	S6.3	S5	S4
	SDR33	SDR26	SDR21	SDR17	SDR13.6	SDR11	SDR9
	PN0.63	PN0.8	PN1.0	PN1.25	PN1.6	PN2.0	PN2.5
	nominal wall thickness en
20	-	-	-	-	-	2.0	2.3
25	-	-	-	-	2.0	2.3	2.8
32	-	-	-	2.0	2.4	2.9	3.6
40	-	-	2.0	2.4	3.0	3.7	4.5
50	-	2.0	2.4	3.0	3.7	4.6	5.6
63	2.0	2.5	3.0	3.8	4.7	5.8	7.1
75	2.3	2.9	3.6	4.5	5.6	6.9	8.4
90	2.8	3.5	4.3	5.4	6.7	8.2	10.1
110	2.7	3.4	4.2	5.3	6.6	8.1	10.0
125	3.1	3.9	4.8	6.0	7.4	9.2	11.4
140	3.5	4.3	5.4	6.7	8.3	10.3	12.7
160	4.0	4.9	6.2	7.7	9.5	11.8	14.6
180	4.4	5.5	6.9	8.6	10.7	13.3	16.4
200	4.9	6.2	7.7	9.6	11.9	14.7	18.2
225	5.5	6.9	8.6	10.8	13.4	16.6	-
250	6.2	7.7	9.6	11.9	14.8	18.4	-
280	6.9	8.6	10.7	13.4	16.6	20.6	-
315	7.7	9.7	12.1	15.0	18.7	23.2	-
355	8.7	10.9	13.6	16.9	21.1	26.1	-
400	9.8	12.3	15.3	19.1	23.7	29.4	-
450	11.0	13.8	17.2	21.5	26.7	33.1	-
500	12.3	15.3	19.1	23.9	29.7	36.8	-
560	13.7	17.2	21.4	26.7	-	-	-
630	15.4	19.3	24.1	30.0	-	-	-
710	17.4	21.8	27.2	-	-	-	-
800	19.6	24.5	30.6	-	-	-	-
900	22.0	27.6	-	-	-	-	-
1000	24.5	30.6	-	-	-	-	-
Note:Nominal wall thickness en will be subject to design stress σS12.5MPa

HDPE pipes and fittings are made from a thermoplastic material, which means they can be melted and re-melted to form different shapes and sizes. Here are some of the key characteristics of HDPE pipes and fittings: High Strength: HDPE pipes and fittings have high tensile strength and can withstand heavy loads. They are resistant to cracks and breakage under normal operating conditions. Chemical Resistance: HDPE pipes and fittings are resistant to a wide range of chemicals, making them suitable for use in corrosive environments. UV Resistance: HDPE pipes and fittings have excellent UV resistance, making them ideal for use in outdoor applications. Flexibility: HDPE pipes and fittings are flexible, making them easy to install and adapt to changes in the piping system. Lightweight: HDPE pipes and fittings are lightweight, which makes transportation and installation easier and more cost-effective. Longevity: HDPE pipes and fittings have a long service life, with a lifespan of up to 100 years, making them a reliable and durable choice for piping systems.
PVC pipes advantage
1) PVC pipe is low in wasted energy, it's 70 KJ/m3, steel is more than 4.5 times than PVC. It's fit the philosophy that advocating green earth and energy conservation.
2)Inside of PVC pipe is smooth, water rate is 0.009 faster than rough factor, but lower than other
material pipe. It can save about 20% electricity by using transfusion.
3) PVC pipe has good function of mechanics and stands corrosive nature, light and easy to install, don't need to maintain. The
usage life for at least 50 years, it's about 2.5 time than metal pipe.
4) PVC pipe can save 16-37% in installation and service fee than iron pipe. As conduit can save 30-33% than metal conduit. Using
in hot and cold water, can save 23-44% that use the same size of brass pipe.
5) Water dissolve teat approves that PVC pipe can not affect the water quality; it's the best choice for the water.. Company Profile
