6mm 80mm Fiberglass duct Rod For Cable Pusing and Pull Rod

Product Description

Product Description
Product Description
6mm 80mm Fiberglass duct Rod For Cable Pusing and Pull Rod
Fiberglass duct rodder description:
Fiberglass duct rodder, sometimes called python rod by its nature passing through under ground ducts by up and
down negotiating the duct curvature, thus very convenient to pull the cables or wires inside the duct. what's
more, it can be used to located the duct block or damage positions.
It has high safety aspects to be applied to underground applications because of its non-conductivity of
electricity, thus sets a major safety to site workers.
It has been built with rigid sturdy fiberglass tubular fabrication for easy usage at site and can be self coiled in
the tubular frame and easily roll like trolley on ground by its wheels fitted at bottom.
Fiberglass duct rodder features:
1>. Non-alkali fiberglass-durable working life time.
2>. ABS coating--smooth surface,non-conductivity
3>. Inside copper wire--detachable
4>. Tilting handle and rubble wheels--easy to carry and move
Fiberglass duct rodder detailed pictures show:

Name	Duct Rodder, Snake rod, Push Pull Rod
FRP rod diameter	φ4mm--φ18mm,
Length	30m--500m
Frame size	1.2*1.2*0.45m	1m*1m*0.45m	1.5*1.5*0.45m
fiberglass rod inner Material	:Extruded by fiber glass and high strength resin at high temperature
fiberglass rod outer Material	High Density polyethylene coating
Frame meterial	Steel with high-temperature sprayed plastic or hot dip galvanized
Min Bend Radius	9mm, 250mm,330mm
Glass Fiber Density	210kg/m, 245kg/m
Breaking tension	2400kg, 4200kg
Working Temperature	-40°C--80°C

We accept customized
Note: Various sizes and colors are available, customization is supported!
We can offer customized fibreglass rodders, such as United Kingdom Style, Australia Style, United States Style and so on. Copper
tracer wire can be added in the core of fiberglass rod.Popular rod color as yellow/orange/bule/red/white,etc. Metal frame can be red/blue/black/silver,etc. Logo can be added on rod to replace meter mark.
Information about Lanyu FRP Cable Push Duct RodderFRP rodder information
1. Light weight, durable, good resistance to chemical and corrosion.
2. High tensile strength and bending properties to make it go through narrow pipes easily.
3. good temperatures adaptability, it will not soften in hot weather nor become brittle in cold weather, its usability will not be affected by temperature.
4. Rod jacket: developed composite materials, hard, smooth and wear-resistant.
5. meter marks are available
6. Rod colors: yellow, other colors are optional
Frame and reel information
1. Equipped with brake device, the rotating or stopping of the rod can be easily operated by hand.
2. Tilting type handle, convenient for pushing and pulling.
3. Guide roller and fixed ring: fix the rod end; protect the rod jacket from being scratched.
4. Frame color: yellow, other colors are available.
Detailed Images
Accessories
Packing & Delivery
Related Products
FAQ & Contacts
Q: Are you trading company or manufacturer ?
A: We are manufacturer with our own factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge. And the freight cost will on the buyer's side.
Q: What is your terms of payment ?
A: Payment<=USD1000, 100% in advance. Payment>=USD1000, 30% T/T in advance ,balance before shipment.
If you have other questions, please feel free to contact us as freely.

---
