Djf (a) Series Swung Drop Hammer Ventilation Exhaust Fan Axial Flow Fans Wall Mounted Shutter Electrical Fan for Poultry Farm House Shed Equipment

US$165.00
10-67 PCS
US$164.00
68+ PCS

Basic Info.

Model NO.
DJF(a)
Usage
Ventilation and Cooling Equipment
Application
Chicken Layer Broiler Duck Pig
Power Source
Electric
Heating and Ventilation Equipment Type
Air Duct
Certification
ISO9001:2008, CE
Condition
New
Warranty
2 Years
Shutter Opening Systme
Drop Hammer, Weight Hammer
Frame Material
Galvanized Sheet
Zinc Coating
275g/Sqm
Blade
Stainless Steel 6PCS
Belt Tensioner
Advanced Belt Tensioner
Belt
Jananese Mitsubishi
Bearing
Imported Bearing
Shutter
8PCS
Motor
Good Quality Chinese Motor
Belt Pulley
High Strength Aluminum-Magnesium
Size
1380*1380*400mm 50inch
Install
Wall Window Mounted
Name
Swung Drop Hammer Ventilation Exhaust Fan
Apply
Poultry Farm Green House Industrial Workshop
Transport Package
Standard Paper Carton
Specification
11 specifications
Trademark
Yuyun Sanhe
Origin
China(Mainland)
HS Code
8414809090
Production Capacity
300PCS/Day

Product Description

DJF(a) Series Swung Drop Hammer Exhaust Fan

Product Application:DJF(a) Series Swung Drop Hammer Exhaust fan are widely used in Agriculture and industry ventilation and cooling. It is mainly used for animal
husbandry, poultry house, livestock breeding, greenhouse, factory workshop, textile etc. Technical Parameter:
Model
 Drive
 Blades Diameter
(mm)		 Blades Rotational Speed Motor Rotational Speed Air Flow
(m³/h)		 Noise Decibels
(db)		 Input Power
(W)		 Voltage
(V)
 Frequency
(HZ)
 Outline Size
(H*W*T) (mm)
DJF(a)-620 Direct 500 1400rpm 1400rpm 5700 ≤70 370
220 / 380/ Customized
50 / 60		 620*620*450
DJF(a)-750 Direct 600 960rpm 960rpm 10600 ≤70 370 750*750*450
DJF(a)-780 Direct 710 960rpm 960rpm 23000 ≤70 750 780*780*420
DJF(a)-780-2 Belt 710 650rpm 1400rpm 18000 ≤65 370 780*780*400
DJF(a)-830 Belt 720 660rpm 1400rpm 20000 ≤65 370 830*830*400
DJF(a)-900 Belt 750 630rpm 1400rpm 22000 ≤65 750 900*900*400
DJF(a)-1000 Belt 900 610rpm 1400rpm 25000 ≤65 750 1000*1000*400
DJF(a)-1060 Belt 960 600rpm 1400rpm 29000 ≤65 750 1060*1060*400
DJF(a)-1100 Belt 1000 600rpm 1400rpm 32500 ≤64 750 1100*1100*400
DJF(a)-1220 Belt 1100 460rpm 1400rpm 38000 ≤64 750 1220*1220*400
DJF(a)-1380 Belt 1270 439rpm 1400rpm 44000 ≤64 1100 1380*1380*400
DJF(a)-1530 Belt 1400 325rpm 1400rpm 55800 ≤64 1500 1530*1530*400

Product Description:
Fan blades
1. Material : 430 stainless steel, thickness 1.2mm
2. Diameter: 1270mm
Advantage:
Large air flow, no deformation, no fracture, no dust, attractive and durable.
Note:
Blade material also have galvanized sheet, aluminum alloy for option
Belt Pulley
1. Material: High strength aluminum-magnesium alloy by die-casting.
2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability
Advantage:
Light weight, Low vibration ,attractive appearance.
Bearing
Imported double-row bearing with special waterproof design.
Advantage:
High strength, low noise, free maintenance and long service life.
Opening System
1.Material: High quality Nylon PA66
2.Guide Rod: 304 stainless steel with special material outside, high strength, no rust, reduce friction.
3.Rivet: 304 stainless steel , wear-resisting, no rust.
Advantage:
It can keep the shutters open at complete 90 degree to ensure the lowest air resistantce and biggest air volume.
Belt
Brand: Mitsuboshi belt (Japanese)
Type: A type
Advantage:
Famous brand, Long service life, maintenance free
Blade Support Base
1.Material: Aluminum Magnesium Alloy.
2. Type: Plug-in connection
Advantage:
Compare with the traditional welding connection , Our new type Aluminum magnesium alloy base has greatly reduced the friction coefficient, fixed more firmly, avoided
Motor
1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor
2. Motor Protection Grade: IP55
3. Isulation Class: F grade
Advantage:
Motor voltage and frequency can be customized.
Chinese famous motor OEM by special design for fan, the first put in the phase lack protection device which would power off when shortage of electricity.

About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
