Heli 5 Ton Diesel Forklift Truck Cpcd50 with Lifting Height 3m in Stock

Product Description

Heli 5 Ton Diesel Forklift Truck Cpcd50 with Lifting Height 3m in Stock Product Description
Power system
Equipped with Chinese powerful and reliable engines with excellent enviromental performance,original imported With all kinds of Japan engine and America engine are optional
Security system
Equipped with OPS or ORS seat and brake switch to prevent incorrect operation and secure the driver and the forklift from all sides
Lighting system
Equipped with full set of LED lamps,which are brighter and energy saving.
Reliable lifting system
Wide-view mast design,providing superior vision,making the operation more security.
High performance hydraulic system
Equipped with load sensing priority hydraulic system,flexible steering,mast lifting speed increased by 20%.
Comfortable driving space
Lengthened wheelbase design,reasonable functional layout,super comfortable and larger ddriving space.
Environmental Friendly
- The emission meets EC and EPA new regulation.
- High-efficiency hydraulic system to lower the fuel consumption.
- Using environmental friendly material.
- Damping device on the mast to reduce impact and vibration.
- Sound insulating and absorbing device is used to reduce the noise.Ergonomics design
- Using power braking system to reduce footplate strength.
- Control lever right located to effectively reduce drivers arm tiredness.
- Dual combined switch lever as a car to enable easy operating.
- Wide mast with good visibility.
- Wide space for boarding and driving, increasing leg space.
- Engine automatic monitor control, when the engine oil pressure is too low or water temperature is too high, the engine will be automatically shut off.Safety performance
- Enclose cabin is made of assembling steel plate, high strength overhead is designed to ensure safety.
- Parking brake with a safety protection device, when the parking brake is working, the forklift will not move even the direction lever is turned.
- Safety device in mast hydraulic system prevents material from falling down in case of hose broken.
- High-pressure hose is designed far away from the driver.
- Safety wire harness, using a waterproof plug.
Product Parameters

1	Manufacturer		VMAX
2	Model	Unit	CPCD50
3	Power type		Diesel
4	Rated capacity	kg	5000
5	Load center	mm	500
6	Operator type	mm	Drive in seat
7	Max. lift height of mast with Load-backrest	mm	4280
8	Max.lift height of fork(standard)	mm	3000
9	Height of mast (standard)	mm	2330
10	Free lift height(standard)	mm	140
11	Height of Load-backrest	mm	1240
12	Distance from seat to overhead guard	mm	1000
13	overhead guard height	mm	2245
14	Length with fork	mm	3110
15	Front overhang	mm	565
16	Rear overhang	mm	553
17	Wheel base	mm	2100
18	The height of traction pin	mm	350
19	Min. ground clearance	mm	160
20	Overall width	mm	1480
21	The distance between forks	mm	1370/300
22	Tread(front /rear)	mm	1180/1190
23	Min. Turning radius(outside)	mm	2740
24	Min. Turning radius(inside)	mm	270
25	Min. Intersecting aisle	mm	3365
26	Mast tilt angle	deg	6° / 12°
27	Fork size	mm	1220*150*55
28	Max.Drive speeds(with/without load)	km/h	18/19
29	Lifting speeds (with load)	mm/s	440
30	Lowering speeds(with /without full load)	mm/s	350/400
31	Max. tractive force	KN	20
32	Max.grade ability (with/without full load)	%	18/20
33	Total weight	kg	6400
34	Weight Distribution full load (front/ rear)	kg	9540/1360
35	Weight Distribution zero load(front / rear)	kg	3630/3770
36	Quantity of wheels		4 X / 2
37	Type of tyres		Penumatic tires
38	Front tire		300-15-18PR
39	Rear tire		7.00-12-12PR
40	Driving Brake		hydraumatic pedal
41	Parking Brake		Mechanical manual
