Road Pavement Fully-Automatic Trailer-Mounted Falling Weight Deflectometer (FWD)

Product Description

Automatic Falling Weight Deflectometer (FWD)
Trailer type & Single point / multi point

Technical specification: Hammer weight: 450KG Moving speed: 0~120km/hour Testing speed per point: 25~30s Deflection type: magnetoelectic speed sensor Deflection sensor q'ty: 1~9pcs selectable(standard config is 9pcs) Deflection range: ±2500um Deflection accuracy: 2% Deflection repeatability: 1% Loading force: 12~150KN (can extend to 250KN) Loading pulse shape; essentially half-sine Loading repeatability: 2% Loading resolution; 0.1KN , 1Kpa Temp. Measuring range: -50C ~ 100C Temp. Resolution: 0.1C Temp. Accuracy; 0.5% DMI sensor type: pulse coder DMI sensor q'ty: 1pc GPS locating: horizontal within ±2meter

Customer Visit

Business Scope
Packaging
Clients Feedbacks

FAQ
1. How long is the delivery time?
Normally goods will be shipped out within 7-10days after contract signed and down payment received.
2. Is it possible to make our own brand/logo on your product?
Yes, but depends on MOQ.
3. What's your MOQ?
This depends on different types of products. If it is a large machine, the MOQ is usually 1 set. For small instruments, such as thermometers, the MOQ is 50 pieces.
4. What kind of payment term you accept?
Normally,
1) If total contract value less than USD 10,000.00 : 100% T/T in advance after contract signed.
2) If total contract value more than USD 10000.00 : 50% T/T in advance after contract signed and 50% T/T after receipt of BL copy. Or, irrevocable LC is acceptable.

---
