Fx-430 BPA Type Good Flexibility Epoxy Vinyl Ester Resin Used in Various FRP Molding Products and Acid, Alkali and Organic Solvent Resistant Chemical Industry

Product Description

FX-430 resin is synthesized by the reaction of methacrylic acid, bisphenol A and epoxy resin and has passed SGS food certification.Product Description The Product Characteristic:
The resin has the characteristic of good flexibility and is widely used in various FRP molding products and acid, alkali and organic solvent resistant chemical industry.
Application:
Application areas: FRP products, ships, storage tanks, pipelines, floors, flue gas desulfurization industry, chemical industry anti-corrosion, metallurgical industry, etc.
Molding process: hand lay-up, continuous pultrusion, spray forming, filament winding, compression molding, resin transfer molding (RTM technology) and vacuum infusion.
The resin structure formula is as follows:
Product ParametersProperties of the Liquid resin:

Property	Unit	Value
Chroma	Gardner	0-6
Acid Value	KOH mg/g	6-13
Viscosity(at 25ºC)	Mpa.s	300-500
Gel Time(at 25ºC)	Min	10-20

Properties of Casting Body :

Property	Unit	Value
Tensile strength	MPa	75-85
Breaking Elongation	%	6-8
Bending strength	MPa	115-145
Bending modulus	GPa	2.8-3.2
Distortion Temperature	ºC	115-125
Barcol hardness	-	36-40
Volume Shrinkage	%	7.0-8.0

Properties of Fiberglass Product:

Property	Unit	Value
Tensile strength	MPa	95
Bending strength	MPa	145
Bending modulus	GPa	4.9
Barcol hardness	-	50

Usage and Storage:
1. This information is based on GB8237-2005 standard, according to the company's professional technical research, combined with the user's application practice.
2. Since there are many variable factors in the process of using the product, it is recommended that necessary tests and experiments should be carried out before using the product.
3. If users can't find the required products or problems in this document, please contact Fangxin directly, we will do our best to provide services according to the needs of users.
4. Unsaturated polyester resin products belong to three types of flammable dangerous goods, storage and transportation shall be handled according to the relevant provisions of the state.
5. Unsaturated polyester resin should be stored in the shade, avoid fire. Waterproof and sunscreen are also needed, as well as heat isolation. Storage life below 25ºC is three months.ApplicationThe resin is suitable for the production of translucent plates, ventilation pipes and other FRP products.
The resin is suitable for the production of translucent plates, ventilation pipes and other FRP products.Our Advantages
Company Profile
Founded in 1992 with a registered capital of 226 million RMB and fixed assets of over 500 million RMB, Fangxin Resin is aprivate joint-stock enterprise specializing in R&D, production and sales of unsaturated resin, vinyl ester resin, alkyd resin,acrylic resin, waterborne resin, color gel coat, color paste and other products.Fangxin has three companies under control: Jiangsu SaiXin resin Co., Ltd., Nantong Fang Xin Chemical Co., Ltd., Changzhou Fang Xin Chemical Material Co., Ltd. It covers an area of 120,000 square meters, equipped with the leading DCS automatic control production equipment in the industry, advanced quality control and technical support laboratory, the entire factory has more than 50 resin production lines, with annual production capacity of 300,000 tons, all of which can achieve sales revenue of more than 4 billion RMB. FAQQ: Is your company a manufacturer?
A: Yes,we are. As the same time,we are agents of other product brands.
Q: Can I get a sample?A: Yes,we can provide 1kg for resin as free samples, but freight usually requires the buyer to bear.
Q: I want to find the most suitable resin for my product. Can you make it customized? A: Yes, as long as it is the needs of customers, we will do our best to satisfy, please contact our customer service, introduce your company's products and requirements, we first introduce or arrange to sample the most close to the parameters of the product,after you test we'll discuss the specific modification parameters.
Q:What is your company's transportation form? A: Samples generally deliver by international express,a large number of goods can be transported by land or water.
Q: How long is the delivery time? A: The products in our product list are basically in stock.If the customer needs to purchase the original specifications,it will be within 1-2 weeks.If you need to arrange special packing or change product parameters,we will also help you with the production and delivery as soon as possible.
Q:What's the payment? A: 50% payment by T/T in advance,50% payment by T/T before shipment.
Q:Can I get a low price if I order a large quantity ? A: Sure,The price of the MIC is just a reference,because of the raw material price floating is bigger,before purchasing,you need contract with our sales,according to your purchase quantity and request,we will give you the lowest price.
Q:What's shelf life of the unsaturated polyester resin ? A:At least 3 months,but if add accelerator,that is 50 days.

---
