| US$5,000.00-10,000.00 | 1 Set (MOQ) |
| Products Information | ||
| Product Name | Plastic Injection Mold Sanitary Wares Closestool Toilet | |
| Shaping Mode | Plastic Injection Mould | |
| Surface treatment | Polish. Etched. Texture | |
| Ejection System | Ejector pin | |
| Part Material | ABS | |
| Part Size(MM) | 21.5*50.3*15.4 | |
| Mold Standard | HASCO standard | |
| Packaging | According to customers' requirement | |
| Mould Steel | A plate | S50C |
| B plate | S50C | |
| Cavity Insert | S136 (HRC 45-50 ) | |
| Core Insert | S136 (HRC 45-50 ) | |
| Slider Insert | 2344 | |
| Ejector Plate | S50C | |
| Spare Parts | S50C | |
| Mould Description | Mould Size(L*W*H MM) | 300*560*250 |
| Mould Gross Weight(KGS) | 965 | |
| Mould Life Time(Shots) | 1,000,000 | |
| Mould Manufacturing Cycle | 35 days | |
| Surface Finish | Polishing | |
| Runner Description | Hot runner | |
| Ejection System | Eject blade | |
| Cycle Time(Second) | 45s | |
| Injection Gate Type | Side gate | |
