Boiler Bimetal Thermometer Manufacturer CE ISO

Product Description

Company profile
ANHUI DOROFU INDUSTRIAL CO.,LTD and Anhui Techunion Electrical Technology Co.,Ltd , locating in tianchang city, close Shanghai . we are specialize in the development, manufacture, marketing and after-sales service of nonwoven products , like nonwoven face mask, nonwoven shoe cover , isolation gown and etc and trade of medical disposable products and all kind of temperature sensor, cables, wires, bridge tray,thermometer,pressure gauge and other related products. TECHUNION has an excellent design team and a highly efficient management team. We have strict internal management systems and highly talented technicians who have rich working experience in industrial instruments. In addition, we have set up several departments, including R&D, Production, Sale and Service. We always insist on the spirit of "responsibility and trust". Thus, our corporation has won trust and compliments from customers.
Our factory also has passed CE ISO9001:2000,Rohs certifications.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
Products Description
High quality Industrial stainless steel Electric contact bimetal thermometer
1. Electric Contact Bimetal Thermometer
2.Dial Size: 100mm
3.Temperature:0-100C
4.Thread:1/2NPT
5.Stem Length:60mm
6.Stem Diameter:6mm
7.We can also make according to client's requirements.

Product Name	High quality 4inch Industrial Electric contact bimetal thermometer
Dial:	100mm
Type	Electric contact
Range	0~500 deg C
Accuracy	±1.0%,±1.5%
Wetted parts:	All Stainless Steel 304 or 316
Connection:	Lower entry, 1/2"
remark	-220v 140mA≈30.8W,single upper limit, double upper limit, upper lower limit, double lower limit, single limit

Name	Bimetal Thermometer
Dial	2.5Inch 3 Inch 4 Inch 5 Inch 6 Inch
Temperature	-50 to 50C / 0-100C/0-200C/0-300C/0-400C /0-500C/0-600C ( or Customized)
Stem Material	Stainless Steel 304 Corrosion Resistance
Dial Material	Alluminum
Window	Strong And Clear Glass
External Reset	Yes at the back case of thermometer
Thread	1/2NPT BSP G1/2 1/4NPT 3/4NPT Ect
Stem Length	20/25/30/40/50/60/70/80/100/150/200/300/400/500/600/700/800/900/1000mm Or Customized

Product Name	High quality industrial bimetal thermometer temperature gauge
Dial:	2",2.5",3",4",5", and 6", aluminum
Case:	AISI 304 stainless steel
Lens:	Glass standard, Shatterproof Glass Len Is Available
Bezel:	AISI 304 stainless steel, hermetically sealed or detachable
Pointer:	Aluminum, painted black
Connection:	1/4"NPT standard on 2" dial, fixed centre back and bottom 1/2"NPT standard on 3", 4", 5" and 6" available, fixed centre back, bottom and adjustable angle.
Accuracy:	+/-1.5% full scale standard; +/-1% full Scale Available

Feature
Name: High quality WSSX series Electric contact bimetal thermometer
Electric contact bimetal thermometer overview
Electric contact bimetal thermometer used in production field of temperature control and alarm automatically. Can be directly measured in the process of various production - 80 ºC to + 500 ºC within the scope of liquid, steam and gas medium temperature.
Electric contact bimetal thermometer key features:
1. The scene shows that temperature, intuitive and convenient;
2. With automatic cut off power and alarm functions;
3. Safe and reliable, long life;
4. Many kinds of structure forms, can meet different requirements.
Electric contact bimetal thermometer working principle :
Electric contact bimetal thermometer is the use of lead contact changes when temperature changes, when touch point contact with the upper and lower limits or disconnected at the same time, make the circuit of relay action, to control and alarm automatically.
Dial nominal diameter: 100
Precision level: 1.0, 1.5
Thermal response time: 40 s or less
Protection grade: IP55
Normal working atmosphere conditions: temperature 25 + 55 ºC, relative humidity 85 or less.
Error: set point set point error should not exceed the basic error of 1.5 times.
Switch: switch bad error should not exceed the basic error of 1.5 times.
Electric contact bimetal thermometer Type and specification :

Type	Measuring Range ºC	accuracy class	protective tube	specification L(mm)	Install fixture
WSSX-400	-40-+80 0-+50 0-+100 0-+150 0-+200 0-+300 0-+400 0-+500	1.5	1Cr18Ni9Ti 304 316 316L hartz C-276	75 100 150 200 300 400 500 750 1000	No fixed device
WSSX-410
WSSX-480
WSSX-401					Movable external thread
WSSX-411
WSSX-481
WSSX-402					Movable internal thread
WSSX-412
WSSX-482
WSSX-403					Fixed screw thread
WSSX-413
WSSX-483
WSSX-404					Fixed flange
WSSX-414
WSSX-484
WSSX-405					Adjustable thread joint
WSSX-415
WSSX-485
WSSX-406					Adjustable flange
WSSX-416
WSSX-486

Related products
Certificated

Factory equipment
Please identify the following items when ordering:
1. Fixing method
2. Single or duplex
3. Lead cable Length
4. Lead cable Material
5. Protection material
6. Protection length
7. Probe Length
8. Probe Diameter
9. Stainless steel armor tube material
10. Stainless steel armor tube length

---
