Professional Household Automatic Fish Pond Filter

Product Description

Product Description Principle
The automatic drum filter(PEHD series), is made in China with advanced German technology, is a low-energy mechanical filter. Its principle is that after polluted water flows into the drum, suspendedsolid larger than filter perforations in the water will be retained in the drum by the micro mesh and discharged by the sewage pipe. The polluted water flowing through the micro mesh is purified and then flows out of this micro-filter system.
Advantage
1. The tank and cover are made of corrosion resistant and UV resistant German PEHD plate, with long life.
2. Built-in bypass, no need to interrupt water circulation in case of emergency, no need to install an external bypass pipeline.
3. The gear is made of corrosion resistant and high hardness material with low maintenance.
4. Siemens PLC or Omron timer, automatic flushing.
Technical data
Filtration: 20μ-90μ(as standard)
Filter surface: Max. 5.4m2
Max capacity:up to 225m3/h(at 90μ,SS≤10mg/l)
Scope of application
Suitable for circulating aquiculture system (fresh water and seawate)randscape water treatment system and industrial wastewater treatment system
Product Parameters

Product model	Flow (m³/h)	Overall size (mm)	Weight (kg)	Backwash pump power (kw)	Reducer power(kw)
HDF-20	32	955*960*797	75	0.75	0.15
HDF40	46	1015*1056*706	97	0.75	0.15
HDF60	65	1235*1215*860	147	0.75	0.15
HDF150	155	1738*1080*860	180	1.1	0.15
HDF200	225	2080*1315*1035	290	1.5	0.15

Solution
Exhibition
FAQ Q: What are your factory main products?
A: we are fous on aquaculture equipment produce.The main products are Automatic Drum Filter,Automatic Feeding System,UV Sterilizing Device,Fish Tank and Other RAS Devices.
We can supply the the overall solution of tilapia RAS fish farm, including project consulting, design, construction, RAS equipment and maintenance services.
Q: What is your product warranty ?
A: The warranty is 12 months while the lifetime is 10-15 years under good maintenance.It is durable and anti-corrosion.

Q: What is the payment term ?
A: Our payment is T/T , 60% deposit, 40% balance payment before shipment.

Q: We haven't imported before, can you ship the goods to our warehouse?
A: Yes. Although our normal trade term is EXW, FOB, CIF, we can also arrange logistics to your warehouse.

Q: How to assemble the equipment once we received it?
A: The CAD install instruction, assembly procedure and project case will be provided.,Of course our skilled installation engineers
would go to your country and install the equipment if needed.

Q: What is your MOQ?
A: Normally, our MOQ is 1 set.

---
