| US$55.00-60.00 | 100 Pieces (MOQ) |
| Camera Module No. | KLT-USB-0446-0447 V1 |
| Resolution | 3.1MP / 1.2MP |
| Image Sensor | AR0331 (Color) + AR0130 (B/W) |
| Sensor Type | 1/3" / 1/3" |
| Pixel Size | 2.2 um x 2.2 um / 3.75 um x 3.75 um |
| EFL | 3.00 mm |
| F.NO | 2.50 |
| Pixel | 2480 x 1536 / 1280 x 960 |
| View Angle | 89°(DFOV) 76°(HFOV) 60°(VFOV) |
| Lens Dimensions | M12 / M12 |
| Module Type | Fixed Focus |
| Lens Model | KLT-LENS-0446-0447 V1 |
| Interface | USB 2.0 |
| Output Format | MJPG / YUV2 |
| Auto Control | Saturation, Contrast, Acutance White Balance, Exposure |
| Audio | None |
| Input Voltage | DC 5V |
| Working Current | Max 500mA |
| PCB Size | 38.00 x 28.00 mm |
| System Compatibility | Windows XP (SP2, SP3), Vista, 7, 8, 10, 11 Android, Mac OS, Linux or OS with UVC Driver Raspberry Pi by USB Port |
| Software for USB Camera | AMCAP, Webcam Viewer, V4L2 Controls Contacam, VLC Player, MotionEye OS iSpy, ZoneMider, Yawcam |
| Lens Type | 650nm IR Cut / 850nm IR Pass |
| Operating Temperature | -30°C to +85°C / -30°C to +70°C |
| USB Cable | KLT-Cable-U018 |
