I Series New Refrigerant Vacuum Pump

Product Description

Product Parameters

Model		YK-i220SV	YK-i240SV	YK--i260SV	YK-i280SV	YK-i120SV	YK-i140SV	YK-i160SV	YK-i180SV
Power Supply		220V~/50Hz	220V~/50Hz	220V~/50Hz	220V~/50Hz	220V~/50Hz	220V~/50Hz	220V~/50Hz	220V~/50Hz
Flow Rate	50Hz	1.8 CFM 51 L/min	3.5 CFM 100 L/min	5.0 CFM 142 L/min	7.0 CFM 198 L/min	1.8 CFM 51 L/min	3.5 CFM 100 L/min	5.0 CFM 142 L/min	7.0 CFM 198 L/min
	60Hz	2.0 CFM 57 L/min	4.0 CFM 113 L/min	6.0 CFM 170 L/min	8.0 CFM 226 L/min	2.0 CFM 57 L/min	4.0 CFM 113 L/min	6.0 CFM 170 L/min	8.0 CFM 226 L/min
Ultimate Vacuum	Partial Pressure	2x10-1Pa	2x10-1Pa	2x10-1Pa	2x10-1Pa	2pa	2pa	2pa	2pa
	Total Pressure	15 micron	15 micron	15 micron	15 micron	15 micron	15 micron	15 micron	15 micron
Power		1/3 HP	1/2 HP	3/4 HP	1 HP	1/4 HP	1/3 HP	1/2 HP	3/4 HP
Inlet Port		1/4" SAE	1/4" SAE	1/4" SAE	1/4" SAE	1/4" SAE	1/4" SAE	1/4" SAE	1/4" SAE
Oil Capacity		200 ml	325 ml	580 ml	500 ml	250 ml	250 ml	660 ml	660 ml
Dimensions (mm)		318x124x265	338x138x275	395x145x318	395x145x318	290x124x255	318x124x265	338x138x275	395x145x318
Weight		9 kg	11 kg	16.6 kg	17kg	6.7kg	8.6kg	10.3kg	15.4kg

Product Description
Operating
Detailed Photos

---
