Specification
| Kubota 4LZ-4J (PRO988Q-Q) full-feed crawler harvester technical parameters |
| Product model | Kubota4LZ-4J(PRO988Q-Q) |
| Classification | Big Granary |
| Cab type | Air-conditioned cab |
| Overall dimensions | length(mm)(transportation state/working state) | 5570/5620 |
| Width(mm)(transportation state/working state) | 2650/2850 |
| Height(mm)(transportation state/working state) | 2880/2880 |
| Structural quality(kg)/use quality(kg) | 3805/4040 |
| Supported engine | model (China third phase) | V3800-DI-T-ET15 |
| Structural type | vertical water-cooled 4-cylinder turbocharged diesel engine |
| Total exhaust volume(L) | 3.769 |
| Calibrated power(kW) | 72.9 |
| Calibrated speed(r/min) | 2600 |
| Fuel | High-quality diesel(0#) |
| Fuel tank capacity(L) | 140 |
| Running part | crawler | ground length(mm) | 1890 |
|
| Width(mm) | 500 |
|
| Ground pressure(KPa) | Structural quality | 19.7 |
| Quality of use | 21 |
| Transmission type | mechanical transmission + hydraulic continuously variable transmission (HST) |
| Transmission levels | stepless forward and stepless reverse (auxiliary transmission has 3 gears each) |
| Minimum ground clearance(mm) | 273 |
| Header section | Header width(mm) | 2300 |
| Minimum cutting height of mouth(mm) | 40(cutting knife tip) |
| Adapted crops | rice, wheat |
| Feeding volume(kg/s) | 4 |
| Threshing section | threshing drum | type | nail-tooth axial flow type |
| Dimensions(mm)(outer diameter×length) | Φ620×2210 |
| Screening method | Vibrating screen, air separation (air flow sorting) |
| Grain Processing Department | Grain Unloading Method | Mechanical Automatic Grain Unloading (Multi-directional Grain Unloading) |
| Granary capacity(L) | 1400 |
| Grain unloading cylinder | grain unloading port rotation range (degrees), rotation mode | 255 (left rotation), electric motor |
| Grain unloading port rotation range (degrees), lifting mode | 0 (horizontal)-47.6, hydraulic type |
| Grain unloading height range of grain unloading port (mm) (working status) | 2290-4955 |
| Grain unloading port extension distance range (mm) (working status) | 2560-3580 |
| Alarm device | | water temperature, charging, engine oil, Guman, No. 1 and No. 2 auger is blocked, reverse fan |
| Operating hour productivity(hm2/h) | Wheat: 0.4-0.64 Rice: 0.3-0.5 |
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
1. who are we? We are based in Shandong, China, start from 2019, sell to Domestic Market(30.00%), Eastern Asia(20.00%), South America(15.00%), Africa(10.00%), Southeast Asia(8.00%), Mid East(5.00%), North America(3.00%), Eastern Europe(2.00%), Oceania(2.00%), Western Europe(00.00%), Central America(00.00%), Northern Europe(00.00%), Southern Europe(00.00%), South Asia(00.00%). There are a total about 11-50 people in our office. 2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3. what can you buy from us? Tractors, harvesters, balers, spare parts, implements, and so on. 4. why should you buy from us not from other suppliers? null 5. what services can we provide? Accepted Delivery Terms: FOB, CIF; Accepted Payment Currency: USD, EUR, JPY, CAD, HKD, CNY; Accepted Payment Type: T/T, Credit Card, Western Union; Language Spoken: English, Chinese
