| PC | |
| CPU | Intel® Celeron J4125, Quad core, 2.4GHz, Fanless, Core i3/i5/i7 optional |
| Memory | 2G/4G/8G DDR3 optional |
| Hard Drive Capacity | 32G/64G/128G/256G/512G SSD |
| Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
| Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
| Network | 1xRealtek RTL 8111E Gigabit Ethernet controller |
| Wireless Network | WIFI |
| I/O Interface | 4xUSB 2.0, 2xUSB 3.0, 2xCOM RS232 |
| 1xVGA/HD-MI/RJ45/Audio OUT/MIC IN/POWER DC | |
| Operation System | Support Windows 10, Linux, Ubuntu, Debian, etc. |
| LCD panel | |
| Panel size | 10" ~ 23" |
| Resolution | 1024*768, 1280*1024, 1920*1080 |
| Aspect ratio | 4:3, 16:9, 5:4, 16:10 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 300 nits |
| Response time | 5ms |
| Contrast ratio | 1000:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | Project Capacitive Touch (10 points) |
| Touch Interface | USB (RS232 optional) |
| Touch response time | 2ms |
| Luminousness | 90% |
| Surface Hardness | 7H |
| Working life | >50 million times |
| Touch options | (5 wire resistive touch, IR touch optional) |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Silver, Black, white, color can be customized |
| VESA mounting | 75x75mm/100x100mm |
| IP grade | Front panel IP65 waterproof |
| Operating Environment | |
| Temperature Range | operating: -10 to 60°C, storage: -20 to 80°C |
| Relative humidity | 5%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Other | |
| Mounting (options) | wall mounting brackets (optional) |
| desk stand holder (optional) | |
| Warranty | 1 year warranty |
