Hot Sales Durable and Sturdy High Precision X5036 X5040 Horizontal Universal Milling Machine

US$7,000.00
1-2 Sets
US$6,800.00
3+ Sets

Basic Info.

Model NO.
bw
Type
Knee-and-Column Milling Machine
Object
Metal
Structure
Knee Type
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Precision
Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Weight (Kg)
190000
Table Size
1600*360mm
Travel
720/320/460
Arm Travel
550mm
T-Slots(No./Width/Pitch)
3/18/80
Transport Package
Customized
Specification
Customized
Trademark
bw
Origin
China

Product Description

Max dia
 MM
 2500
 3150
 4000
Table dia
 MM
 2250
 2830
 2830/3150
Max workpiece height
 MM
 1600
 1600
 2000
Max workpiece weight
 T
 10/20
 10/20
 10/20
Max torque of table
 KN.M
 63
 63
 63
Table rotate speed range (16step)
 R/MIN
 2-63
 2-63
 2-63
Max cutting force of the vertical holder
 KN
 32
 35
 35
Vertical toolholder move limit
 =
 ±30°
 ±30°
 ±30°
Range of feed rates(stepless)
 MM/MIN
 0.1-500
 0.1-500
 0.1-500
Horizontal travel of rail head
 MM
 1400
 1725
 2150
Ram travel of rail head
 MM
 1000
 1000/1250
 1000/1250
Fast moving speed of tool heads
 MM/MIN
 3500
 3500
 3500
Knife rod cross-section size (W.D.)
 MM
 40x50
 40x50
 40x50
Main motor power
 KW
 DC/AC:55
 DC/AC:55
 DC/AC:55
Overall size of machine
 CM
 540x470x480/520
 605x440x493/533
 690x510x480/ 520/570
Weight of machine
 T
 38
 40/42
 50/52
Ram section
 MM
 240x240
 240x240
 240x240
