| Model | CK 6140 (GSK980TC3 system) |
| Processing ability | Unit ( mm ) |
| Max. swing over bed | Φ400 |
| Max. swing over slide | Ф240 |
| Max. Processing length | 750mm |
| Travel | |
| X/Z axis travel | 240/750mm |
| X/Z axis minimum displacement unit | 0.001 |
| Spindle | |
| Spindle bore diameter | Ф58 |
| Pull tube hole diameter | Φ55 |
| Spindle inner hole taper | 40° |
| Spindle series | stepless |
| Max. spindle speed | 150-2000 rpm |
| Workpiece clamping mode | Manual chuck K11-200 |
| Main motor power | 5.5 kW |
| Feed turret | |
| X/Z axis torque | 5/7.5 N.m |
| X/Z axis rapid speed | 6/8 m/min |
| Turret type | Electicity |
| Tool shank size | 25×25 |
| Turret repeatability | ≤0.004 |
| Tailstock | |
| Tailstock diameter | Φ65 |
| Tailstock travel | 150 |
| Tailstock center taper | Morse 4# |
| Others | |
| Machine net weight | 1800kg |
| Machine dimension(L×W×H) | 2500×1500×1700 |
| Power supply(power/ electric current) | 11kW/20A |
| Standard configuration | |
| Chuck | Ф200 manual chuck |
| Tailstock | Manual tailstock |
| X axis ball screw | Domestic(Qishan)FD3210-889-1035 |
| Z axis ball screw | Domestic(Qishan)FD2506-407-530 |
| Electricity turret | 4 position |
| X,Z axis screw bearing | Domestic(Derun) |
| Spindle bearing | Domestic P5 |
| Machine casting | Highquality resin sand casting |
| Spindle assembly | Assembly spindle |
| Oil paint | Can be customized color |
| Lubrication | Domestic |
