| Activation | Mechanical |
| Parts | Precision pressure regulator |
| Relieving exhaust | with relieving air exhaust |
| Housing | Die cast zinc |
| Sealing material | Acrylonitrile butadiene rubber |
| Nominal flow Qn | 480 l/min |
| Compressed air connection | G 1/4 |
| Version | Regulator without pressure gauge |
| Parts | Precision pressure regulator |
| Mounting orientation | Any |
| Working pressure min./max. | 0,5 … 16 bar |
| Ambient temperature min./max. | -10 … 60 °C |
| Medium temperature min./max. | -10 … 60 °C |
| Medium | Compressed air Neutral gases |
| Regulator type | Diaphragm-type pressure regulator |
| Regulator function | with relieving air exhaust |
| Adjustment range min./max. | 0 … 1 bar |
| Pressure supply | single |
| Activation | Mechanical |
| Weight | 1,02 kg |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . Relieving exhaust (≤ 10 mbar over set pressure) Mounting: mounting bracket R412004872 or installation in piping | |
| Recommended pre-filtering | 0,3 µm |
| Housing | Die cast zinc |
| Seals | Acrylonitrile butadiene rubber |
