6 Basktes Aluminum Extrusion Machine Double Door Aging Oven

Product Description

6 material baskets double door aging oven technical parameters
I Aging furnace and technical parameters:
1. Machine name and mode: single aging oven, gas heating, Large flow of hot air circulating fan.
2. Furnace inside size: 7000×1920×2235mm (Lx W x H)
3. Material baskets size: 6000×800×600mm (Lx W x H)
4. Furnace outside size: 8000×2240×3200mm (Lx W x H) not including the fans size.
All together are 6 baskets.
5. The max temperature: 250ºC.
6. Heating mode: Gas, direct fire and circulating heat.
7. The buyer supply water: pressure 0.2 Mpa. Consumption: 4m³/h, power: 380V 50Hz;

NO	Name	Material specification	Quantity	Remarks
1	Charging car system	Charging car, reducer, chain	2set
2	Steel plate	A3 plate folder, plate 2mm thickness	supporting
3	Bottom and roof plate	A3plate 2mm thickness	supporting
4	Thermal insulation layer	Aluminum silicate fiber cotton	supporting	Both size thickness is 200mm
5	Chassis, corners, top shelf	10#,8# U international steel	supporting
6	Fans supporting	10# U international steel	supporting
7	Skeleton, rack bars	60*40 square tube,4# iron	supporting
8	Door	A3 weld steel plate(Asbestos packing seal)	2 set	160mm thickness,
9		20# U international steel	supporting
10	Charging car	10# U international steel	2 set

---
