Non Rotating Ungalvanized Steel Wire Rope 35X7 for Crane with Yellow Grease

Product Description

Product Parameters Steel wire rope constructions & diameters :

Surface	Construction	Diameter (mm)	Tensile Strength
Ungalvanized,	1x7	0.6--14	1270N/mm2--1960N/mm2
Electric galvanized,	1x19	1.0--8.0
Hot dipped galvanized,	1x12	1.0--8.0
PVC/PE/NYLON,	7x7 (6x7+IWS/IWRC)	1.0--20
Stainless steel AISI304/316	6x19+IWS/IWRC	3.0--56
	6x19W/S+IWS/IWRC	6.0--38
	6x37+IWS/IWRC	6.0--64
	6x19/25Fi+IWS/IWRC	6.0--44
	8x19S/W+IWRC	8.0--16
	8x19S+IWRC	8.0--16
	6x36WS+IWRC	8.0--56
	19x7	4.0--28
	6x19+FC	3.0--56
	6x19W/S+FC	6.0--36
	6x37+FC	6.0--64
	6x19Fi+FC	6.0--44
	8x19S/W+FC	8.0--16
	8x19S+FC	6.0--16
	6x36WS+FC	8.0--56
	6x24+7FC	6.0--56
	6x12+7FC	3.0--32
	18x7+FC	4.0--28

Non Rotating Steel Cable 35X7 used for Equipment for port load and unload tower crane .

diameter	approx weight	nominal tensile strength of rope (MPA)
MM	KG/100M	1570	1670	1770	1870	1960
		minimum breaking load of rope (KN)
8	27.5	36.1	38.4	40.7	43	45.1
9	34.9	45.8	48.7	51.6	54.6	57.1
10	43	56.5	60.1	63.7	67.3	70.6
11	52	68.4	72.8	77	81.5	85.3
12	62	81.4	86.6	91.8	96.9	102
13	72.7	95.5	101.6	107	113	119
14	85	111	118	125	132	138
15	96.8	127	135	143	151	158
16	110	145	154	163	172	181
17	124	163	173	184	194	204
18	140	183	195	206	218	229
19	155	204	217	230	243	254
20	172	226	240	255	269	282
21	189	249	265	281	296	311
22	208	274	291	308	326	342
23	227	299	318	337	356	373
24	248	326	346	367	388	406
25	268	353	375	398	420	441
26	292	382	406	431	455	477
27	313	412	438	464	490	514
28	338	443	471	500	528	553
29	362	475	505	535	566	593
30	388	509	541	573	606	635
31	413	543	577	612	646	678
32	440	579	616	652	689	723
33	468	615	654	693	733	768
34	498	653	695	737	778	816
35	526	692	736	780	824	864
36	558	732	779	826	872	914
37	588	773	823	872	921	965
38	621	816	868	920	972	1020
39	654	859	914	969	1023	1073
40	690	904	962	1020	1080	1130
41	722	950	1010	1071	1131	1186
42	760	997	1060	1120	1190	1240
43	795	1045	1111	1178	1244	1304
44	834	1090	1160	1230	1300	1370
45	870	1144	1217	1290	1363	1428
46	910	1196	1272	1348	1424	1493
47	949	1248	1328	1407	1487	1558
48	992	1302	1385	1468	1551	1625
49	1032	1357	1443	1529	1616	1694
50	1075	1413	1503	1593	1683	1764

Detailed Photos
Packaging & Shipping Steel wire rope Packaging & Shipping
Our usual steel wire rope packages are in wooden reels, plastic reels, wooden case, cartons, and soft coils, etc. We can also provide unique packing for our clients, such as in blister, pp bags, hard plastic, corrugated package, and according to clients' request, bar code, brand or other pattern and words can also be printed in the package to meet the need of sales in supermarket or shops.
The usual shipping port is Nantong and Shanghai, we have professional workers to guide the container load, promise to put all the cargos in order, not slant or damaged.


After Sales Service Nantong Sanjayro Import & Export Co.ltd Services:
1. We promise to send the offer within 24 hours.
2. 100% qualified products can be guaranteed.
3. Products will be finished within the shortest lead time.
4. We guarantee to provide the best after-sales services.
5. Clients' requirements will be met as far as possible.
6. Free steel wire rope samples can be provided.
7. Competitive factory bottom prices will be quoted.
8. Clients' visit to our factory is welcome anytime.
9. Test report will be provided with the true test data.
10. Our trading company has a good source of rigging, chains, tools, etc. factories.
Company Profile
Nantong Sanjayro Import & Export Co. Ltd was established in 2004. It already has much experience in steel wire rope manufacturing. Factory has a total area of 35000m2, with 400 skilled workers, over 150 production apparatus and ISO9001 certificate. Sanjayro specializes in producing spring steel wire, galvanized steel wire, elevator steel wire rope, stainless steel wire rope, galvanized and ungalvanized steel wire rope, aircraft wire rope, etc. The annual yield is nearly 20000 tons, produced by standards of GB, DIN, ANSI, JIS, ASTM, ISO, etc. Sanjayro steel wire rope has been exported to many regions including North America, South America, Europe, Africa, Southeast Asia, Middle East, etc.

FAQ How to give an accurate offer?
1. Construction, such as 1x7, 6x7, 8x19, 6x37, etc.
2. Core, such as fiber core or steel core, etc.
3. Diameter, such as 2mm, 10mm, 20mm, 50mm, etc.
4. Surface, such as electric galvanized, hot dipped galvanized, ungalvanized or stainless
5. Quantity, such as 3000m, 5000m or 20 tons, 25 tons, etc.
6. Length per reel, for example 10m/reel, 100m/reel or 1000m/reel, etc.
7. Package, such as wooden reel, plastic reel, soft coil, wooden case, carton, etc.

---
