| US$30,000.00-300,000.00 | 1 Piece (MOQ) |
| Projects | Value | Remarks | |
| Working performance parameters | **Large rated gross lifting capacity kg | 220T | |
| The basic arm ** has a large lifting moment kN.m | 8750 | ||
| The main boom** large lifting height m | 80 | Regardless of boom deformation, the values in parentheses are plus the standard knob value | |
| Boom** large lifting height m | 112 | ||
| Job velocity | Main winch single rope** high speed m/min | 113 | **Four floors |
| Sub-winch single rope** high speed m/min | 56 | **Three floors | |
| The boom extension time is min | 18 | ||
| Boom boom boom time s | 100 | ||
| Rotation speed r/min | 0~1.3 | ||
| Driving parameter | **Large use altitude m | 2000 | |
| **High travel speed km/h | 72 | ||
| Large climbs % | 48 | ||
| **Small turn diameter m | 24 | ||
| **Small ground clearance mm | 355 | ||
| Exhaust pollutant emission values and smoke limits | Comply with standard regulations | GB3847-2005 GB17691-2005 (State V.)) | |
| Fuel consumption per 100 km L | 95 | 50Km/h at a constant speed | |
| quality parameter | Driving weight (gross mass) kg | 72000 | The hook, counterweight, jib, auxiliary winch, arm tip pulley, foot plate, and rear movable outrigger of the crane in the driving state cannot be driven with the vehicle and need to be disassembled. |
| size parameter | Dimensions (L×W×H) mm | 17752×3000×4000 | |
| The longitudinal distance of the outriggers is m | 8.8 | ||
| The lateral distance between the legs is m | 8.8 | ||
| The main arm is m long | 15.4 ~ 80 | ||
| Main arm elevation angle ° | -0.6 ~82 | ||
| Boom length m | 12/20/28 | ||
| Boom + overlift connecting frame m | 16/24/32 | ||
| Boom mounting angle ° | 0,15,30 | ||
