Product Description
Product Description
Automatic mosquito-repellent incense making machine
Introduction
Automatic mosquito-repellent incense making machine
Automatic mosquito coil incense making machine
Complete set equipment of making mosquito repellent incense
Anti-mosquito incense making machine
The device is designed for all hydraulic equipment. Photo electric at the beginning of the
usage of the PLC controller, automatic machines, simples structure, easy operation
and maintenance, high performance, easy mold replacement,
cylinder working stroke is short.
Mosquito incense making machine:
1. Raw material: charcoal powder, starch powder,wood powder etc.
ing system:raw material mixer- coil forming machine-drying machine-spraying
machine-packing machine-inspect -packing-stock.
3. Need machine: big mixer, small mixer, broth mixer, forming main machine, elevator
(drying machine),drying stove ( built by yourself ),putting machine, spraying machine,
packing machine.
4. Volot:380 V, 50 HZ
Parameter
Number
| Machine name
| Model
| Number
| Mark
|
1
| Big mixer
| THJB-A2200
| 1
| With elevator,screening
|
2
| Small mixer
| THJB-200
| 1
|
|
3
| Broth mixer
| THBJ-50
| 1
|
|
4
| Forming main machine
| THWXJ-18/VI
| 1
|
|
5
| Elevator
| JYJ-0.75
| 2
| For dring machine
|
6
| Fan machine
| 7.5KW 50,000 m³/hour
| 2
| For drying machine
|
7
| Coil collector
| THSX-3.45
| 1
|
|
8
| Putting machine
| THFP-1.3
| 1
|
|
9
| Order machine
|
| 2
|
|
10
| Spraying machine
| THPY-300
| 1
|
|
11
| Packing machine
|
| 1
|
|
1.big mixer
Motor:20.1kw, capacity:2200KG/time,batch time:30 min/time,size:2800×3500×5100mm
2.small mixer
Motor:11KW,capacity:200KG/time,bathc time:12 min/time,size:2800×1300×1300mm
3.broth mixer
Motor:1.5KW,capacity:50KG/time,,size:750×1700mm
4.forming main machine
Capacity:22680 pcs/hour(in 18-mode),motor:27.65 KW,worker:4,
Sieve plate size::900*450*40 mm,
machine size:5300×5000×1800mm
5.elevator
Motor:1.5 kw
6.fan
Motor:7.5KW,,volumn:50000m³/hour. Size:Φ1200mm
llecting machine
Motor:3.45KW,capacity:6-8 bacth/hour,,size:3500×2400×1400mm
8.putting machine
Motor:1.34KW,putting speed:18000 pcs/hour,,size:2700×1600×600mm
9.spraying machine
Motor:1.2KW,spraying speed:300 pcs/min,,size::2800×3500×5100mm
>>
