| Table size（L x W） | 760x850mm | |
| Max working thickness | 150mm | |
| Max working width | 600mm | |
| Main saw spindle diameter | Ф30mm | |
| Shaper spindle diameter | Ф70mm | |
| Main saw spindle speed | 2840 rpm | |
| Shaper spindle speed | 6000rpm | |
| Shaper spindle power | 11kw | |
| Main saw spindle power | 4kw | |
| Butting saw power | 2x0.75kw | |
| Total power | 16.5kw | |
| Overall dimensions | 2700x1730x1550mm | |
| Net weight | About 2000kg |
