| SPECIFICATION |
| Size/weight/button |
| Size | 84.5 mm*56.3 mm*27.3 mm |
| Weight | 163g |
| Button | Front big Record button and top Record button easy operation |
| Yellow PTT button |
| Yellow SOS button(Panic button) |
| Hardware |
| Chipsets | Ambarella H22 |
| Sensor | OS05A20 |
| Indicators |
| 3 color LED indicator for camera status |
| 3 color LED indicator for battery level |
| Programmable buzzer; Vibration |
| Light |
| IR | IR upto to 10 meters at 0 lux with visible shape image |
| Flash Light | 90 degrees view angle light source for low light condition can enable/disable by button press |
| Laser | Optional(position the object to record,enable/disable by button) |
| Durability |
| Shock Proof | 1.8 m (5.9ft) |
| IP Rating | IP67 |
| Video/picture/audio |
| Coding | .H.264/H.265 |
| View Angle | FOV 140 degrees |
| Video Resolution | 2560X1440P 30FPS,1920X 1080P 30FPS (Chipsets support 4K,limit to 1080 for lower power consumption) / 1080P60 / 720P30 / 720P60 / 480P30 |
| Video Streaming Resolution | 720P30 / 480P30 / 320P30 |
| Audio Streaming | Support |
| Text Streaming | Support |
| Streaming Bitrate | 300kbs-4M kbs |
| Snap Shot | During recording |
| Video Format | MP4 |
| Picture format | JPEG |
| Audio Format | AAC |
| EIS | 6 axis image stabilizer(Optional) |
| SOS | Audio alarm activates in all cameras at same group and audio |
| alarm in command certer |
| External Camera |
| External Camera | Support |
| Night Vision | Ultral low light performance & IR LED |
| Storage | Optional 32 GB,64 GB,128 GB,256 GB |
| Hardware Interface |
| USB Port | Support external camera connection |
| Pogo Pin connection | Support dock & go operation |
| Wireless Connections |
| Wi-Fi | 2.4G&5G, AP/STA/P2P,Wi-Fi channel can be set by cam manager |
| Bluetooth | Support Heartbeat Rate activate recording, Remote controller, support re-development |
| ONVIF | Support ONVIF streaming & recording
Support NVR brand such as Hikvision, Dahua, Uniview and so on |
| IR | 10 meters (2 IR LED) |
| GPS | Support |
| 3G/4G | Built in 3G/4G module(FDD-LTE/WCDMA/GPRS) |
| Clustered Talkback(PTT) | Optional (camera talk to camera, camera talk to command center, command talk to cameras);can set cameras to groups from camera GUI or from command center software |
| Alarm | SOS button to activate warning signal in camera and in command center and advise command center the position of camera |
| Text message | Camera can send text message to camera or command center |
| Protocol |
| TCP/IP, RTSP, RTMP, GB/28181/JSON |
| Battery |
| Recording Time | 1080P Up to 14 Hours;480P Up to 16 Hours |
| GPS and Wi-Fi on at 480P30 12 hours and 30 minutes |
| Standby Time | 100+ hours |
| Charging Time | 4 hours |
| Streaming&Recording time | 7.5 hours(3G/4G version) |
| Pre&post recording |
| Pre-recording | 30 seconds to 60 seconds varies from resolution settings |
| Post-recording | 30 seconds to 60 seconds from resolution settings |
| Motion Detect | Support |
| Security Features(Optional) |
| File Encryption | AES256 encryption during writing files to memory card |
| AES256 encryption RTSP Video/audio/Text streaming data |
| Network Security | Https&Http Server |
| Wi-Fi Security | Dynamic Pin Code authentication |
| USB Command&JSON command |
| all camera settings available under mass storage mode |
| all camera settings available under USB simple mode |
| USB heart beat available |
| Control over LED/buzzer available under mass storage mode |
| Ambarella driver free even while USB encryption activated |
| Support driver free connection to computer |
| Mount solution |
| Standard mount | 360 degrees rotatable crocodile mount |
| Optional mount | MOLLE compatible mount |
| Optional accessoires | CLICKFAST Stud |
| Video Stamp |
| Content supported | User ID/Device ID/Date/Time/Geo-tags/Logo |
| Others |
| Working Temperature | -30 -65 degrees celsus |
| Operating Humidity | 95% |
