Innovative EDM Wire Cutting Machine with 1-Year Warranty on Parts

Product Description

Product model	DK7720	DK7735	DK7745F	DK7745	DK7750
Worktable stroke (mm)	420*270	710*480	920*540	810*570	950*650
Table travel (mm)	200*250	350*450	450*700	450*550	500*630
Machining height (mm)	200	480	480	480	600
Machining taper (mm)	6°,15°,30°/80
Cutting speed (m/min)	≥120
Surface roughness/finish(um)	≤2.5
Electrode wire diameter (mm)	0.1-0.2
Electrode wire fixed line speed (m/s)	11.5
Processing accuracy	According to GB7926-2005 standard≤0.02mm
Table movement pulse equivalent (mm)	0.001
Power supply	50Hz.380V
Machine tool power consumption (KVA)	<1.0
Workpiece weight (KG)	100	300	450	450	700
Main machine external dimensions (mm)	1160*810*1300	1240*1170*1400	1700*1600*1600	1600*1240*1400	1720*1680*1700

Product model	DK7750F	DK7763	DK7763F	DK7780	DK77100
Worktable stroke (mm)	1140*650	1140*750	1350*750	1350*985	1700*1170
Table travel (mm)	500*800	630*800	630*1000	800*1000	1000*1200
Machining height (mm)	400/600	600	600/800	600	1000
Machining taper (mm)	6°,15°,30°/80
Cutting speed (m/min)	≥120
Surface roughness/finish(um)	≤2.5
Electrode wire diameter (mm)	0.1-0.2
Electrode wire fixed line speed (m/s)	11.5
Processing accuracy	According to GB7926-2005 standard≤0.02mm
Table movement pulse equivalent (mm)	0.001
Power supply	50Hz.380V
Machine tool power consumption (KVA)	<1.0
Workpiece weight (KG)	700	1000	1000	2000	2600
Main machine external dimensions (mm)	2000*1900*1700	2100*1940*1780	2300*2200*1800	2600*2400*1800	3000*2800*2500

Company Profile
Jiangsu Sanlin Technology Equipment Co., Ltd. Jiangsu Sanlin Technology Equipment Co., Ltd. stands as a beacon of innovation and reliability in the realm of high-tech enterprises, expertly blending production, research, development, and sales of cutting-edge CNC machinery and equipment. With decades of experience in the equipment industry, we have mastered the art of crafting machinery that caters to a vast array of applications. Our comprehensive portfolio includes vertical machining centers, high-speed machines, gantry machining centers, drilling and tapping centers, as well as engraving and milling machines, gantry engraving and milling machines, medium wire cutting machines, fast wire cutting machines, small hole machines, and sanding machines. Each piece of equipment is designed with precision and a commitment to quality that has gained us the admiration and trust of our valued clients. Our products serve critical manufacturing sectors such as automotive, aerospace, national defense, medical food machinery, rail transit, and metal mold production. With a strong national presence and expanding international reach to Southeast Asia, Europe, Africa, and beyond, Jiangsu Sanlin Technology Equipment Co., Ltd. remains dedicated to continuous improvement. We warmly invite customers and friends to engage in fruitful collaborations as we consistently deliver exceptional products tailored to your needs.
FAQ
A: As a proud manufacturer, we extend a warm invitation for you to visit our factory to witness our craftsmanship firsthand. A: To choose the perfect machine, begin by aligning the worktable travel and cutting thickness with your workpiece dimensions, ensuring an ideal fit. Then, verify that the precision and surface quality align with your expectations; our TRS series machines offer superior precision and an unmatched finish. A: Absolutely, we can adjust the machine's voltage to match your country's requirements—just let us know the specifics. A: Enjoy the peace of mind with our free replacement of damaged parts throughout the warranty period. Post-warranty, replacements are available at cost. Should any issues arise, you can rely on our swift support, whether through detailed video guides or other effective solutions.Q: Are you a manufacturer or distributor? Q: How to choose the machine I want? Q: Our country's voltage is three-phase 220V (or single-phase 220V, or another voltage), while the machine's voltage is three-phase 380V. Can you change the voltage? Q: How about after-sales service?

---
