product propertiesProperty ValueSelect properties
| manufacturer: | Texas Instruments |
|
| Product Category: | Instrumentation Amplifier |
|
| RoHS: | details |
|
| series: | INA128 |
|
| Number of channels: | 1 Channel |
|
| 3dB bandwidth: | 200 kHz |
|
| SR - Slew Rate: | 4 V/us |
|
| CMRR - Common Mode Rejection Ratio: | 120 dB |
|
| Ib - Input Bias Current: | 5 nA |
|
| Vos - Input bias voltage: | 250 uV |
|
| Supply Voltage - Maximum: | 36 V |
|
| Supply Voltage - Minimum: | 4.5 V |
|
| Working power supply current: | 700 uA |
|
| Minimum operating temperature: | - 40 C |
|
| Maximum operating temperature: | + 125 C |
|
| Installation style: | SMD/SMT |
|
| Package/Case: | SEC-8 |
|
| Package: | Reel |
|
| Package: | Cut Tape |
|
| Package: | MouseReel |
|
| Amplifier Type: | Instrumentation Amplifier |
|
| trademark: | Texas Instruments |
|
| Dual supply voltage: | +/- 15 V |
|
| en - Input voltage noise density: | 8 nV/sqrt Hz |
|
| Gain Error: | 0.012 % |
|
| Gain V/V: | 1 V/V to 10000 V/V |
|
| GBP - Gain Bandwidth Product: | 1.3 MHz |
|
| high: | 1.58 mm |
|
| INL - Integral Nonlinearity: | 0.012 % |
|
| length: | 4.9 mm |
|
| Maximum input resistance: | 100 GOhms |
|
| Moisture Sensitivity: | Yes |
|
| Working power supply voltage: | 4.5V to 36V |
|
| product: | Instrumentation Amplifiers |
|
| product type: | Instrumentation Amplifiers |
|
| Factory Packing Quantity: | 2500 |
|
| Subcategory: | Amplifier ICs |
|
| width: | 3.91 mm |
|
| unit weight: | 76 mg |
|
